Economic Best-Selling infrared ceramic emitter heater

Specifications

infrared ceramic emitter heater
1.fast response, Rapid heat-up
2.Certificate: CE.

Economic Best-Selling infrared ceramic emitter heater



Ceramic infrared heaters are 96% infrared energy efficient.

Uses for electric infrared heat can be found in many industries applications,

and can be grouped into four major categories:

1. Curing.

2. Drying.

3. Heating.

4. Cooking.

5. Saunas.



Top right have has a wide range of IR ceramic heaters in ceramic and Quartz.

Available With thermocouple & without thermocouple from 60 watts to 1000 watts.



Feature of infrared ceramic emitter heater:

1. Durable, splash-proof, non-corrosive finish.

2. Watt densities from 3 w/cm² (tolerance within +/- 2%).

3. Maximum temperature output is 1292 F (700 C.).

4. Available color in white/ black/yellow.

5. Standard voltages: 220/230v (other volts available on request).

6. Estimated life in excess of 10,000 hours.

7. Available With thermocouple & without thermocouple.



Parameter of infrared ceramic emitter heater:

Model	RE926-C
Brand	Resucerial
Applications	Plastic thermoforming,Blowing of plastic bottles, chemical industry, light industry, electronics, medicine, food
Radiation Wavelengths	1-25um
Certificate	CE
Life Time	1500h
Heating Resistance Wire	Ni-Cr-Al Alloy wire
Material	quartz sand
Shape	flat,curved
Color	white/black/yellow
Voltage	12v,24v,36v,75v,110v,120v,220v,230v,240v,380v,400v,415v
Watts	100-2000w
Sizes(Mm)	245x65,240x60,120x60,120x120
Power Dflexural Strengthensity	440kg/cm2
Insulation Resistance	>100megohm
Emissivity	0.9
Largest Surface Load	5w/cm2





Size(mm)	Shape	Power( KW )	Size(mm)	Shape	Power(KW)
245×65	arc	0.25-1.0	300×300×16	flat	0.8-1.5
240×60	arc	0.5-1.0	240×160×16	flat	0.6-1.0
125×65	arc	0.2-0.5	Φ70	disk	0.1-0.2
120×60	flat	0.1-0.325	Φ100	disk	0.2-0.3
120×60	arc	0.1-0.325	Φ140	disk	0.3-0.4
120×120	flat	0.1-0.8	Φ150×Φ100×Φ60	half	0.25-0.3
120×120	arc	0.1-0.8	125×125	flat	0.4-0.8



Photos of infrared ceramic emitter heater:













Samples:



Application of infrared ceramic emitter heater:

1. The ceramic heaters are widely used in pre-heating of plastic sheets for vacuum forming & thermoforming, drying paints, lacquer & varnish curing, drying printing inks, drying textiles, activating adhesives, removing surface water from objects or moisture removal from fabric and paper, animal husbandry and rearing.

2. The ceramic IR heaters are highly efficient.

3. Ceramic infrared heater offers precise targeting and control with minimal peripheral heat.

4.  It is possible to apply heat only where and when it is required.

5. The energy in an infrared heater is transmitted at the speed of light from the element to the product.

6.  A constant rate of heating is obtained because the source temperature is normally much higher than that of the product even at the end of the heating cycle.



Certification:



Production Process:





Packing:



Shipping:



Our Team:



Exhibition:



infrared ceramic emitter heater
