10kv 35kv 66kv 110kv 220kv Polymer Insulator

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

GEM

Model Number:

FXBW

Liaoning Mec Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Dalian

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name GEM

Model Number FXBW

Type Insulator

Material Composite Polymer

Application High Voltage

Rated Voltage From 10 to 220

Tensile Strength 80N

Specifications

There are many characteristics of Polymer Insulator, such as light, high mechanical strength, easy installation,lessmaintenance.

Service Conditions:

Please take the following pictures as reference:

Parameters:

No.	Type Code	Rated Voltage (kV)	Rated mechanical tensile strength (kN)	Connecting Mark	Structure height(H) mm	Insulation distance(H)mm	Min. Nominal Creepage distance (mm)	Lighting impulse withstand voltage(peak)>=kV	Power frequency withstand voltage, 1min>=kV	Weight (kg)	Dwg No.
1	FXBW-10/70	10	70	16	400±15	216	450	145	45	2	1
2	FXBW-10/100	10	100	16	435±15	216	450	145	45	2	1
3	FXBW-35/70	35	70	16	615±15	450	1200	230	95	3	2
4	FXBW-35/100	35	100	16	645±15	450	1200	230	95	3	2
5	FXBW-66/70	66	70	16	900±15	720	2100	410	185	4	3
6	FXBW-66/100	66	100	16	940±15	720	2100	410	185	4	3
7	FXBW-110/70	110	70	16	1180±15	1030	3000	550	230	5	4
8	FXBW-110/70	110	70	16	1240±15	1050	3200	550	230	5	4
9	FXBW-110/70	110	70	16	1280±15	1100	3500	550	230	5	4
10	FXBW-110/100	110	100	16	1180±15	1000	3000	550	230	5	4
11	FXBW-110/100	110	100	16	1240±15	1030	3200	550	230	5	4
12	FXBW-110/100	110	100	16	1280±15	1050	3500	550	230	5	4
13	FXBW-110/160	110	160	16	1240±15	1000	3400	550	230	7	4
14	FXBW-110/160	110	160	16	1290±15	1030	3400	550	230	7	4
15	FXBW-220/100	220	100	16	2150±30	2000	6300	1000	395	10	4
16	FXBW-220/100	220	100	16	2240±30	2040	6300	1000	395	10	4
17	FXBW-220/160	220	160	16	2150±30	1900	6300	1000	395	12	4
18	FXBW-220/160	220	160	16	2240±30	1980	6300	1000	395	12	4
