CS GAP-BED LATHE

Liaoning Mec Group Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Turning Center

CNC or Not:

Normal

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Turning Center

CNC or Not Normal

SPECIFICATION	MODELS
	CS6166B	CS6266B	CS6166C	CS6266C
CAPACITY
Swing over bed	660mm(26")
Swing over cross slide	420mm(17")
Swing in gap	870mm(34") (Gap-bed Lathe)
Length in gap	240mm(9.5") (Gap-bed Lathe)
Max. length of workpiece	1000/1500/2000/3000mm (/40"/60"/80"/120")
HEADSTOCK
Spindle nose	ISO702/II No.8 Camlock
Spindle bore	ø82mm(3.3")		ø105mm(4")
Taper of spindle bore	ø90mm(3.5")1:20		ø113mm(4.4") 1:20
Range of spindle speeds	9-1600rpm, 24steps		36-1600rpm,12steps
Max. output of spindle torque	1500N.m		1200N.m
FEEDS AND THREADS
Max. travel of compound rest	145mm(5-3/4")
Max. travel of cross slide	310mm(12-1/5")
Leadscrew pitch	12mm or 2TPI
Section of tool	25×25mm(1×1")
Spindle center to tool support	28mm(1-1/10")
Longitudinal quick moving speed	4.5m(15ft)/min, 50Hz; 5.4m(18ft)/min,60Hz
Crosswise quick moving speed	1.9m/min(6.37ft)/min,50Hz; 2.3m(7.67ft)/min,60Hz
TAILSTOCK
Dia of tailstock sleeve	ø75mm(2-61/64")
Morese taper of tailstock sleeve	MT5
Travel of tailstock sleeve	150mm(5-29/32")
Cross adjustment	±15mm
MOTOR
Power of main motor	7.5KW(10HP),3PH,1450rpm/50Hz; 1750rpm/60Hz
Power of quick-travel motor	250W(1/3HP),3PH
Power coolant pump	90W(1/8HP),3PH
Available voltage/cycle	220V,380V,420V/50Hz,60Hz
DIMENSION AND WEIGHT
Net weight	2400/2600/2800/3000kg
Gross weight	3075/3250/3450/3650kg
