Product Details
Condition: | New | Type: | Gear Hobbing Machine | CNC or Not: | Normal |
Place of Origin: | Shanghai, China | Brand Name: | Neutral | Model Number: | ii |
Product Description
Gear Hobbing Machine
Use and features :
The machine tool is suitable for the batch ,small batch and individual production of cylindrical gear and worm gear ,suitable for roll cutting spline shaft in a certain range of parameters.
The machine tool feartures good rigidness and extremely smal thermal deformation ,enabling high-speed cutting and load cutting ,with a very high prodution efficiency.
The machine tool is convenient for adjustment ,with auto stop mechanism ,as well as reliable safe mechanism and auto lubrication system.
Specification and Parameters
Max diameter of workpiece | 500mm |
Max module of workpiece | 8mm |
Min teeth of workpiece | Zmin/knt=5(*n:nember of cutter |
Max machine width workpiece | 250mm |
Max diameter of cutter | 160mm |
Max length of cutter | 160mm |
Diameler of changeable and axis of cutter | 22 27 32 |
Max rotary angle of headstock | 240° |
Dist between table and axis of cutter | Max 535mm Min 235mm |
Dis between axis of workpiece and axis of cutter | Max 330mm Min 30mm |
Dist between table and bearing end of rear post | Max:830mm Min:380mm |
Dia of mandrel of workpiece | 30mm |
Step number and range of spindl speed | 63-320r.p.m |
Main motor power | 3Kw |
Range of axial step | 0.4-4mm/table per turn |
Dimensions(L×W×H) | 2439×1272×17070(mm) |
