Home > Instruments & Meters > Optical Lens & Instrument > Microscope > Product Nomenclature

Product Nomenclature

Name: Product Nomenclature
Brand: ToupTek
SKU: 100661263
Availability: InStock

Negotiable MOQ: 20 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

ToupTek

Model Number:

Product Nomenclature

Contact Supplier Request Quote Chat Now

Hangzhou ToupTek Photonics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name ToupTek

Model Number Product Nomenclature

Specifications

1.Scientific Naming Conventions
2.Easy to Extendable
3.Easy to Recoverable

Product Nomenclature

	UHCCD	05100K	P	A	-U	-ET	-S	-C	-SQ	-NA
	1	2	3	4	5	6	7	8	9	10
1	Series Name: SCCCD, U3CCD, U3CMOS, EXCCD, UHCCD, UCMOS or SCMOS
2	Pixel Number: eg. 05100K: 5.1 Mega pixels
3	Color Mode, M: Monochromatic; P: Polychromatic
4	Sensor Distinguishing Code, such as A, B, C or D…
5	Data Output Interface Model, U: USB; D: DVI; V: VGA; A: Analog
6	Trigger Type, ET: External Trigger; NA: Not Available
7	Cooled Type, S: Semiconductor Cooled; F: Fan Cooled; N: Natural Cooled
8	Optical-Mechanical Interface Type, C: C-mount; M: Microscope; T: Telescope; S: Sporting Scope
9	Mechanical Shape , CY: Cylinder; SQ: Square; CP: Compact
10	TV System (Analog Cameras Only), PA: PAL; NT: NTSC; NA: Not Available

EXCCD:ToupTek EXCCD camera adopts Sony Exview HAD CCD sensor as the image-picking device. Sony EXview HAD CCD is a CCD that drastically improves light efficiency by including near infrared light region as a basic structure of HAD (Hole-Accumulation-Diode) sensor; ToupTek uses EXCCD for simplicity; USB2.0 is used as the data transfer interface.
UHCCD:ToupTek UHCCD camera adopts Sony CCD sensor as the image-picking device; The Super HAD CCD is a version of Sony's high performance CCD HAD (Hole-Accumulation Diode) sensor with sharply improved sensitivity by the incorporation of a new semiconductor technology developed by Sony Corporation. USB2.0 is used as the data transfer interface.
SCCCD:ToupTek SCCCD camera adopts Sony Exview HAD or HAD CCD sensor as the image-picking device. USB2.0 is used as the data transfer interface.
UCMOS:ToupTek UCMOS camera adopts Ultra-high performance CMOS sensor as the image-picking device. USB2.0 is used as the data transfer interface.
SCMOS:ToupTek SCMOS camera is an economic edition with simple and compact structure. USB2.0 is used as the data transfer interface.
U3CMOS:ToupTek U3CMOS camera adopts Ultra-high performance CMOS sensor as the image-picking device and USB3.0 as the data transfer interface.
U3CCD:ToupTek UHCCD camera adopts Sony Exview HAD or HAD CCD sensor as the image-picking device; The Super HAD CCD is a version of Sony's high performance CCD HAD (Hole-Accumulation Diode) sensor with sharply improved sensitivity by the incorporation of a new semiconductor technology developed by Sony Corporation. USB3.0 is used as the data transfer interface.
