TR-10N-02

TR-10N-02 thumbnail-1
TR-10N-02 photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SCED
Model Number:
TR-10N-02
Contact Supplier Request Quote Chat Now
Shenzhen Sced Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
YanTian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SCED
Model Number TR-10N-02


TR-10N-02













Parameter and Drawing Specifications:












Description                    Color

Type

Terminal                       Grey

 TR-10N-02

End Cover                      Grey





Fixed Bridge



FBI 10-10        Imax: 76A

Insertion Bridge





Separating Plate



TS-KK3

Partition Plate





Zack Strip                      White

ZB10

Screwdriver

SZS 1.0×4.0

Rail Material

aluminum

Dimensions                             mm

            10.2/56.5/-

Height (U35: 7.5/U35: 15G 32)              mm

59/66.5/64

Screw / Torque                           Nm

M4 / 1.5-1.8

Stripping Length                          mm

11

IEC Technical Data



Max. Load Current / Cross Section         A / mm2

             76 / 16

Rated Surge Voltage / Contamination Class    KV / -

              8 / 3

Surge Voltage Category

               Ⅲ















Competitive Advantage:



1.    Stable good quality

2.    Competitive price

3.    Quickly response

4.    Full range products for selection

5.    Flexible to design the exact part per customers’ demand
