Home > Products > stage speaker > AQ8, mini 8 inch passive 2-way full range loudspeaker, professional speaker

AQ8, mini 8 inch passive 2-way full range loudspeaker, professional speaker

FOB Price

USD $150 - $180 / Piece

10 Pieces(Min.Order)

Supply Ability 300 Piece / Pieces per Month
Port Guangzhou
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	M.Klen
Model Number	AQ8

Product Description

[ Factory, EXW price, quickly shipment, alibaba trade assurance, 10 years of OEM ]:

AQ8 loudspeaker descriptions:

1. The Blackline AQ8 is a versatile , 2-way passive system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure.

2. It features a powerful 8''(200mm) low frequency driver and a 1''(25mm) HF compression driver mounted on a constant directivity 90° x 50° horn.

3. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.

AQ8 loudspeaker features:

1.Versatile, passive 2-way full range system, 1x8''LF + 1x1.4''HF, 8 ohms, 200W - 400W.

2. Full sound, powerful bass, low distortion, pure and natural tone quality, light weight, easy to install safely.

3. Best chioce for nightclubs, bars, Disco, theaters, concert halls, Band, stage performance, wedding, home party, touring performance, etc.

AQ8 loudspeaker specifications:

TYPE	Compact ,two-way passive
FREQUENCY RESPONSE	68Hz-19kHz±3dB 56Hz @-10dB
DRIVERS	LF: 1 x 8″(200mm)/2″(50mm)voice coil LF driver, Ferrite HF: Voice coil HF driver size 1.4″(34mm), Ferrite
SENSITIVITY	96dB/W/M
MAXIMUM SPL	116dB continuous,122dB peak
NOMINAL IMPEDANCE	8 ohms
RATED POWER	200W RMS, 800W peak
FITTINGS	8×M8,4×M8 threaded inserts 1×mounting pole socket
CONNECTORS	2×Neutrik NL4
DIMENSIONS (HxWxD)	440x300x270mm
WEIGHT	13kg

AQ8 loudspeaker box design:

AQ8 loudspeaker driver configuration:

HF:

LF:

Our Services

♥ OEM /ODM orders are warmly welcome ,we can make the varied designs according to your need. Besides, we service alibaba trade assurance.

♥ All the goods are inspected before shipment, so we can ensure the best quality of products .

♥Free warranty service for one year ,within this period ,you can enjoy free maintenance service by warranty cards and invoice if a failure occurs under normal operation.

♥ If you have any problems,please feel free to let us know, by e-mail, telephone ,skype, WhatsApp or the others ,we will reply you as soon as we can.
