[ Factory, EXW price, quickly shipment, trade assurance,10 years of OEM ]:
AQ15 loudspeaker descriptions:
1. The high power AQ15 is a high performance, wide-bandwidth system in an incredibly compact and efficient package.
2. Extended frequency response is provided by a powerful 15''(380mm) low frequency driver and a 1.4''(38mm) HF compression driver mounted on a rotatable 80° x 50° constant directivity HF horn.
3. The AQ15 is perfect for higher power applications where ease of installation or speed of development are important factors.
AQ15 loudspeaker features:
1.High performance, passive 2-way full range system, 1x15''LF + 1x3''HF, 400W - 800W high power.
2. Full sound, powerful bass, low distortion, pure and natural tone quality, light weight, easy to install safely.
3. Best chioce for nightclubs, bars, Disco, theaters,church, concert halls, Band, stage performance, wedding, touring performance, etc.
AQ15 loudspeaker specifications:
| TYPE | Compact ,two-way passive |
| FREQUENCY RESPONSE | 55Hz-18kHz±3dB |
| DRIVERS | LF: 1 x 15″(380mm)/3″(75mm)voice coil LF driver, Ferrite |
| SENSITIVITY | 98dB/W/M |
| MAXIMUM SPL | 121dB continuous,127dB peak |
| NOMINAL IMPEDANCE | 8 ohms |
| RATED POWER | 400W RMS, 800W peak |
| FITTINGS |
12×M8, threaded inserts 1×mounting pole socket |
| DISPERSION (-6dB) | 80°horizontal, 50°vertical |
| CONNECTORS | 2×Neutrik NL4 |
| DIMENSIONS (HxWxD) | 692x470x443mm |
| WEIGHT | 32kg |
AQ15 loudspeaker box design:
AQ15 loudspeaker driver configuration:
HF:
LF:
♥ OEM /ODM orders are warmly welcome ,we can make the varied designs according to your need. Besides, we service alibaba trade assurance.
♥ All the goods are inspected before shipment, so we can ensure the best quality of products .
♥Free warranty service for one year ,within this period ,you can enjoy free maintenance service by warranty cards and invoice if a failure occurs under normal operation.
♥ If you have any problems,please feel free to let us know, by e-mail, telephone ,skype, WhatsApp or the others ,we will reply you as soon as we can.
