PS15TT+ Speaker Features:
♣ A 15" 2-way passive stage speaker, 600-1200watts, with one 15" Neodymium LF and one 3" HF drivers.
♣ Strong penetrating, high fidelity and low distortion, clear, pure and natural tone quality.
♣ With multilayer plywood, environmental protective black painting, newest humanzied design, simple and esay for rigging.
♣ Widely used in AV application system, meeting room, stage, theater, clubs, discos ect.
PS15TT+ is a versatile, 2-way passive system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure. It features a powerful 15″(375mm) low frequency driver and a 1.5″(37mm) HF compression driver mounted on a constant directivity 90°×50° horn. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.
PS15TT+ Speaker Specifications:
PS15TT+ | |
Frequency Response[a] |
58Hz-18kHz±3dB |
Usable Range@-6dB [a] |
55 Hz-20kHz |
Sensitivity 1W@1m[b] |
98dB |
Rated power |
600W AES,1200W peak |
Nominal Peak SRL@1m[b] |
132 dB Peak (for 600 to1200W RMS Amp.) |
HF Dispersion[c] |
50°to 100°Hor. × 55°Vert.Rotatable Horn |
Nominal Impedance |
Passive 8ΩActive; LF8Ω ,Neodymium |
Components |
LF1×15″(375mm),600W,8Ωdriver |
|
HF 3″(75mm) titanium diaphragm, driver+Low Distortion, Constant Directivity Asymmetrical Dispersion Horn. |
Height × Width × Depth |
(H)675 ×(W)434 ×(D)369 mm |
Weight |
25 kg |
Connectors |
3×NL4MP 4-pole SPEAKON;Passive In Passive Loop Thru, Active In |
♦ Our factory supports Alibaba Trade Assurance, 100% product quality protection.
♦ OEM or ODM orders are warmly welcomed, we could produce varies speakers according to your drawings.
♦ Offer 1year free warranty, except the man-made damaged.
♦ All the products will be tested and inspected before the delivery.
PS15TT+ Speaker driver configurations:
Our Showroom & Assembly shop:
