Home > Consumer Electronics > Audio & Sets > Professional Audio > PS15 Hot Sell Pro Speaker, Speaker

PS15 Hot Sell Pro Speaker, Speaker

PS15 Hot Sell Pro Speaker, Speaker photo-1
US$ 250 - 300 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
M.Klen
Model Number:
PS-15
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/ Huangpu
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name M.Klen
Model Number PS-15
Product Description

PS15 is a versatile, 2-way passive system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure. It features a powerful 15″(375mm) low frequency driver and a 1.5″(37mm) HF compression driver mounted on a constant directivity 90°×50° horn. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.







PS15 Speaker Features:



A 15" 2-way passive stage speaker, 400-800watts, with one 15" LF  and one 3" HF drivers.

Strong penetrating, high fidelity and low distortion, clear, pure and natural tone quality.

With multilayer plywood, environmental protective black painting, newest humanzied design, simple and esay for rigging.

Widely used in AV application system, meeting room, stage, theater, clubs, discos ect.







PS15 Speaker Specifications:



PS-15

Frequency Response[a]

58Hz-18kHz±3dB

Usable Range@-6dB [a]

55 Hz-20kHz

Sensitivity 1W@1m[b]

98dB

Nominal Peak SRL@1m[b]

126 dB Peak (for 400 to 800W RMS Amp.)

HF Dispersion[c]

50°to 100°Hor. × 55°Vert.Rotatable Horn

Crossover Frequencies

 900Hz Passive or Active (internally switchable)

Directivity

Q&DI[c]Q:16 Nominal DI:12dB Nominal (f>3kHz)

Crossover Frequencies

2kHz Passive

Nominal Impedance

Passive 8ΩActive; LF6.5 Ω ,HF8 Ω

Recommended Amplifiers

400 to 800 Watts into 8Ω

Components





LF1×15″(380mm)6.5Ωdriver

Voice coil HF driver size 3″(72mm)

Constant Directivity Asymmetrical Dispersion Horn.

Height × Width × Depth

(H)675   ×(W)434   ×(369)   mm

Weight

 28   kg

Connectors

3×NL4MP 4-pole SPEAKON;Passive In Passive Loop Thru, Active In







Our Services

  ♦ Our factory supports Alibaba Trade Assurance, 100% product quality protection.

 ♦ OEM or ODM orders are warmly welcomed, we could produce varies speakers according to your drawings.

 ♦ Offer 1year free warranty, except the man-made damaged.

  All the products will be tested and inspected before the delivery.









PS15 Speaker driver configurations:



PS15 hot sell pro speaker, speaker







PS15 hot sell pro speaker, speaker
