Pipe End Forming Machine
Use: the machine is used to process tub-end of metal tube and makes them change into
the shape that you want, such as bell-mouth, U shape tube-end and locating ring
etc, which is applied to tube-end machining for air-conditioner, water heater,
airplane and motorcar.
Features:
1) Mitsubishi PLC for centralized control
2) Oil box and machine integrative design
3) Nature cooling
4) Centralized lubricating system of manual mode
5) Counting function
6) Foot switch or push-button box
Specifications:
1) Max. machining pipe diameter: copper φ20mm
2) Max. machining W. thickness: 1.6mm
3) Machining units: 3
4) Machining efficiency: 3p/8sec
5) Electric control mode: PLC
6) Operating mode: auto / manual / jog
7) Loading mode: manual
8) Driving mode: hydraulic pressure
9) Machining mode: cold-forging
10) Punch travel: 100mm (adjustable)
11) Max. clamping force: 2,000kg
12) Max. clamping travel: 30mm
13) Max. wallop: 2,000kg
14) Max. machining depth error: <±0.5
15) Max. coaxial error: <0.1
16) Space between moving die 30mm
17) Power supply: three phase 380V/50HZ
18) Hydraulic motor power: 2.2kW
19) Hydraulic system pressure: 5-8MPa
