Horizontal Plastic Blow Molding Machine

Name: Horizontal Plastic Blow Molding Machine
Brand: zhongyi
SKU: 100589831

US$ 10,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Bottle

Plastic Processed:

Cangzhou Zhongyi Plastic Machinery Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

xingang

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Bottle

Plastic Processed PE

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Hebei, China

Brand Name zhongyi

Model Number WSJ-5

Specifications

horizontal plastic blow molding machine:
1.ours is a manufacture company
2.simple operation
3.save energy
4.fast-speed

Horizontal plastic blow molding machine:

Type	WSJ-5	WSJ-6	WSJ-7
The volume of the product L	≤2.5	≤4	≤6
The quantity of the mouth of the mould	1
The quantity of the moulds(set)	2
Production capacity( without raw material ) pcs /day	1500	1200	1000
Screw diameter mm	55	55	65
Long radius rate L/D	1:25	1:25	1:25
The max plasticizing capacity of HDPE kg/h	40	40	55
Clamping method	Pneumatic
The diameter of clamping cylinder mm	100	125	150
The mothed of cutting the pipe of material	Hot cutting knife
Journey of opening and closing of mould mm	200	230	250
Max dimension of the mould(D×W×H)mm	180×210×300	220×270×350	230×310×400
Blowing pressure Mpa	0.4-0.6	0.4-0.6	0.5-0.7
Gas consumption m3/min	0.5	0.6	0.6
The pressure of cooling water Mpa	0.2-.03
The diameter of water circulation pipe mm	14
The electric machinery power of extruder machine kw	7.5	7.5	11
The heating power of extruder machine kw	8.5	8.5	10.5
Total power KW	16	16	21.5
Appearance dimension of machine mm(L X W X H )	3100×1400×1600	3300×1650×1700	3400×1750×1700
Weight kg	900	1100	1200
Method of control	PLC computer control
The suitable raw material	PE/PP/PS
