PT7200 portable explosive proof Conventional Professional Digital Radio
A professional radio with compact design, full bands coverage&enhanced signaling features, is an ideal partner for your business, which protects the privacy in critical environment. GPS and RFID optional function combining with GIS system provides real time tracking and dispatcher management.
Enhanced 2Tone/5Tone/MDC/DTMF signaling
Up to 16 2-Tone/5-Tone codes can be decoded on a channel. When a matched tone is received, various reprogrammed actions as beep,answer back, stun, LED blink could be activated. Even missed call notice and call transfer are optional for upgraded version. The PT 7200 can also provides the standard MDC1200 signaling.
Tough and reliable design
PT7200 meets waterproof IP 54 where the radio dose not harm when work in the rain. In addition, it meets MIL-810C/D/E/F standards, it could withstand harsh environment.
Long battery life
For better performance, 1700mAh are standard and 2000mAh are optional, the battery’s. life is up to 14 hours.
Powerful audio output
1.6w audio output and voice compander ensure crisp, clear and strong audio quality even in any noisy environment.
Safety Assurance
With lone worker, Mandow(Optional), Security enquire, and kinds of emergency features that assure you safety in case of emergencies or accidents
GPS (Optional)
The PT7200's GPS function, supported by control center and management software, allows uses to be located instantly, either to dispatch among group or locate of an emergency call. Allowing for more efficient use of resources or determining location in life-threatening situations.
Remote Kill/Stun/Activate/Revive
If the radio is killed or stunned, all attempts on operation by user,except power on/off, will be ignored. The radio will be activated or revived only when it received the correct code.
General | |
Frequency Range |
136~174MHz, 400~470MHz |
Channel Capacity |
16 |
Channel Spacing |
12.5KHz/20KHz/25KHz |
Operating Temperature |
-30℃~ +60℃ |
Operating Voltage |
7.5V DC ±20% |
Battery |
1700mAh Li-ion(Standard) 2000mAh Li-ion(Optional) |
Frequency Stability |
±2.5 ppm |
Dimension(with battery and antenna) |
56mm×120mm×35mm |
Weight(with battery and antenna) |
280g |
Transmitter | |
RF Power Output |
4W/2W/1W(UHF) 5W/2W/1W(VHF) |
Frequency modulation |
16KφF3E/11KφF3E |
Antenna Impedance |
50Ω |
Modulation Limiting |
±2.5KHz 12.5KHz, ±4KHz 20KHz, ±5KHz 25KHz |
Radiated Spurious Emission |
-36dBm < 1GHz |
FM Noise |
45dB 25KHz |
Modulation Distortion |
< 3% |
Receiver | |
Reference Sensitivity |
0.28μV 12.5KHz |
Adjacent channel Selectivity |
60dB 12.5KHz |
Intermodulation |
65 dB |
Spurious Response Rejection |
70 dB |
Rated Audio Output |
1W |
S/N |
45/40 |
Rated Audio Distortion |
≤3% |
- Accessories
