DIN Flange Standard Expansion Flexible Rubber Joint Quality Choice

Name: DIN Flange Standard Expansion Flexible Rubber Joint Quality Choice
Brand: BUNDOR
SKU: 100504735
Availability: InStock

US$ 13.68 - 50 MOQ: 1 Set

Key Specifications

Material:

Other, EPDM, NBR, NR, Polarity rubber

Technics:

Other, flexible rubber expansion joints

Type:

Other, Rubber joint

Henan Bundor Flow Control Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Material Other, EPDM, NBR, NR, Polarity rubber

Technics Other, flexible rubber expansion joints

Type Other, Rubber joint

Place of Origin Henan, China

Model Number Rubber Joint

Brand Name BUNDOR

Connection Flange

Shape Other, Rubber

Head Code Other, Circle for flexible rubber expansion joints

Product Description

Technical parameters FOR DIN Flange Standard Expansion Flexible Rubber Joint
Item	KXT-A1	KXT-A2	KXT-A3
Mpa（kgf/cm2）Working pressure	1．0(10)	1．6（16）	2．5（25）
Mpa（kgf/cm2）Explosion pressure	2．0（20）	3．0（30）	4．5（45）
Kpa（mm/Hg）Vacuum	53.3(400)	86．7（650）	100（750）
Applicable Temperature	-15℃-115℃(-30℃-250℃ under special conditions)
Applicable media	Air,compressed air,water,sea water,hot water,oil,acid,alkali,and so on

Name	DIN Flange Standard Expansion Flexible Rubber Joint
Diameter	DN25-DN1200
Medium	Cold and hot water
Pressure	PN1.0-2.5Mpa
Applicable Temperature	-15 degree~+115 degree
Applicable Media	Air,Compressedair,water,sea water,hot water,oil acid and so on.

Detailed Images

Name: Rubber

Brand: BUNDOR

Original: Tianjin

Material: EPDM/ NBR

Machine Parts

Name: Flange
Brand: BUNDOR
Original: Tianjin
Material:DIN/JIS/ANSI/EN

Packing & Delivery

Packaging
Size	110 (L) * 110 (W) * 78 (D)
Weight	800kg
Packaging Details	Hard-to-hard-lay,Put sponge in each floor, 1.11.10.78m export plywood case;

Size	110 (L) * 110 (W) * 78 (D)
weight	About 800kg
Packaging Details	One 20' container can in bulk loaded on 24pcs plywood cases more or less. We can pack according to specific customer requests. Customers' logos are available on package
