Flexible Threaded Rubber Joint
Flexible threaded rubber joint consists of rubber tube and metallic flexible joint. Rubber tube composes of inner glue line, outer glue line and multi-scratch rubber cord enhancement layer. This joint has many advantages such as high patience, good elasticity, large deflection displacement, good shock-absorbing. It is widely used in fan coil units pipelines in the room of hotel and restaurant.
Technical requirement
Working pressure |
16MPa |
Potency dimension |
4.8 MPa |
Operation temperature |
-20-115°C |
Application media |
water,hot air,air |
item |
parts |
materials |
1 |
Hose lining |
Heat resistant rubber |
2 |
Outer sphere |
Provide old rubber |
3 |
Strengthen lining |
cotton Dacron cloth |
4 |
Internal screw thread loose joint |
Malleable cast-iron |
5 |
External screw thread loose joint |
Malleable cast-iron |
Nominal diameter&axial displacement&lateral displacement&angle displacement table
Nominal diameter DN(mm) |
L(mm) |
Axial compress(mm) |
Axial elongation(mm) |
Radial dispersion(mm) |
angular deflection |
|
JGD-B-1N |
JGD-B-1W |
|||||
15 |
180 |
195 |
10 |
5 |
20 |
45°C |
20 |
200 |
220 |
10 |
5 |
20 |
45°C |
25 |
220 |
240 |
10 |
5 |
20 |
45°C |
Nominal diameter&length&displacement data sheet
DN |
length(mm) |
axial |
Axialcompression elongation(mm) |
radial direction(mm) |
angular deflection(mm) |
20*15 |
200 |
10 |
5 |
25 |
45°C |
25*20 |
220 |
10 |
5 |
25 |
45°C |
32*25 |
220 |
10 |
5 |
25 |
45°C |
40*32 |
240 |
10 |
5 |
25 |
45°C |
Note: Main materials and parts asGD-B-1W | |||||
....
