Mitutoyo ABSOLUTE 573-601 Digital Caliper, Steel, Battery Powered, Offset Jaw
US$ 469 - 532
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
MITUTOYO
Model Number:
573-601
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mitutoyo Pocket Type Dial Test Indicator 513-517TUS$ 130 - 198MOQ: 1 Set -
Mitutoyo 511-201 Dial Bore Gauge for Small HolesUS$ 200 - 300MOQ: 1 Set
-
Mitutoyo 511-210 Dial Bore Gauge for Small HolesUS$ 245 - 321MOQ: 1 Set
-
Mitutoyo 422-271 LCD Blade Micrometer, Ratchet Stop, 0-25mm Range, 0.001mmUS$ 724 - 778MOQ: 1 Set
-
Mitutoyo 530-115 Vernier CaliperUS$ 150 - 231MOQ: 1 Set
Place of Origin
China
Brand Name
MITUTOYO
Model Number
573-601
Product Description
0-150mm Range,
+/-0.02mm Accuracy,
0.01mm Resolution,
Meets IP67 Specifications
Product Features
Hardened stainless steel construction for protection of caliper components
Main scale jaw slides up and down to allow for measurement of hard-to-access stepped sections
IP67-rated for protection against dust and temporary submersion in water
Function control buttons on caliper face for ease of access: Origin-set, Zero-setting, Power On/Off, Data Output
Statistical process control (SPC) output transmits results to a Mitutoyo miniprocessor or computer
Hardened stainless steel construction for protection of caliper components
Main scale jaw slides up and down to allow for measurement of hard-to-access stepped sections
IP67-rated for protection against dust and temporary submersion in water
Function control buttons on caliper face for ease of access: Origin-set, Zero-setting, Power On/Off, Data Output
Statistical process control (SPC) output transmits results to a Mitutoyo miniprocessor or computer
Product Description
The Mitutoyo 573 series ABSOLUTE Digimatic offset digital caliper has a sliding main scale jaw for measurement of step sections and uses Mitutoyo’s ABSOLUTE linear encoder technology. This caliper has accessible function control buttons, such as Origin-set, Zero-setting, Power On/Off, and Data Output, and uses the metric measuring system. Although identical to dial and vernier calipers in its ability to make precise measurements, the digital caliper’s LCD increases reading reliability.
The 573 series caliper has the ABSOLUTE electrostatic capacitance type linear encoder to help reduce overspeed errors. LCD resolution is 0.01mm. Functions include Origin-setting, Zero-setting, and Power On/Off automatic shutoff. This caliper is Ingress Protection 67 (IP67)-certified, which means that the electronic components are resistant to debris and to submersion in liquid under standard conditions for up to 30 minutes. An alarm alerts the user to low voltage and counting value composition errors. A rolling thumbwheel makes fine adjustments and a thumbscrew locks the scale’s position. The caliper has Statistical Process Control (SPC) data output capability; it outputs data using a serial data interface to a computer or other dedicated recording device using SPC cable with data switch (sold separately). The caliper includes, and is powered by, a single SR44 silver oxide cell battery that lasts approximately 3.5 years with normal use.
The Mitutoyo 573 series ABSOLUTE Digimatic offset digital caliper has a sliding main scale jaw for measurement of step sections and uses Mitutoyo’s ABSOLUTE linear encoder technology. This caliper has accessible function control buttons, such as Origin-set, Zero-setting, Power On/Off, and Data Output, and uses the metric measuring system. Although identical to dial and vernier calipers in its ability to make precise measurements, the digital caliper’s LCD increases reading reliability.
The 573 series caliper has the ABSOLUTE electrostatic capacitance type linear encoder to help reduce overspeed errors. LCD resolution is 0.01mm. Functions include Origin-setting, Zero-setting, and Power On/Off automatic shutoff. This caliper is Ingress Protection 67 (IP67)-certified, which means that the electronic components are resistant to debris and to submersion in liquid under standard conditions for up to 30 minutes. An alarm alerts the user to low voltage and counting value composition errors. A rolling thumbwheel makes fine adjustments and a thumbscrew locks the scale’s position. The caliper has Statistical Process Control (SPC) data output capability; it outputs data using a serial data interface to a computer or other dedicated recording device using SPC cable with data switch (sold separately). The caliper includes, and is powered by, a single SR44 silver oxide cell battery that lasts approximately 3.5 years with normal use.
