ETCR6300 High Sensitivity Leakage Clamp Meters

Name: ETCR6300 High Sensitivity Leakage Clamp Meters
Brand: ETCR
SKU: 100473933
Availability: InStock

US$ 175.78 - 175.78 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

ETCR

Model Number:

ETCR6300

Qingdao Zhibohongyu Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name ETCR

Model Number ETCR6300

Operating Temperature 0°C~40°C

Dimensions 175mm*70mm*38mm

Weight 120g (With battery)

Product Description

Technical Specification

Function	AC leakage measurement, AC current measurement, On-line AC current measurement
Power Supply	6F22 9V Zi-Mn dry battery 6F22 9V
Process Type	Clamp CT, Integral Approach
Display Type	4 Digits LCD
Clamp Size	25mm*30mm
Meter Dimension	LWH: 175mm70mm38mm
LCD Dimension	35mm21.5mm; Display Dimension: 32mm15mm
Sampling Rate	2 Times/Second
Frequency	50Hz, 60Hz Automatic identification
Shifting	Automatic Shift
Range	0.01Ma~60.00A
Resolution	1uA
Accuracy	±1.5%±5dgt (23°C±3°C, below 70%RH)
Line voltage	Below AC 600V
RS232 Interface	With RS232 interface, Data stored in the memory can be uploaded to the computer, with software monitoring
Data Memory	99 sets, “FULL” Blinking when memory is full
Peak Maintaining	Peak value capture hold function, press HOLD without Release to display peak value
Reading Hold	Reading hold function: “DH” symbol display
Overflow display	Range overflow function: “OL” symbol display
Automatic Shutdown	5 minutes after the boot
Battery Detection	When battery voltage is lower than 7.2V, low battery symbol will shown to remind battery replacement.
Meter Weight	120g (With battery)
Rated Power	5mW
Working Temperature and Humidity	0°C~40°C; below 80%rh
Storage Temperature and Humidity	-10°C~60°C; below 70%rh
Insulation Strength	AC2kV/rms (between core and box)
Safety Provisions	IEC1010-1, IEC1010-2-032, Pollution level 2, CAT III(600V)
Accessories	Meter: 1 piece, RS232 Com-cable:1 piece; Software Disk: 1 piece; Battery (6F22 9V): 1 piece
