H.264 onvif 9ch 1080P NVR with p2p cloud service
Specifications:
Model |
IC-NVR1309 |
IC-NVR1316 |
IC-NVR1325 |
IC-NVR1332 |
Main Processor |
Hisilicon Hi3515 |
|||
Operating system |
Embedded LINUX OS |
|||
Video compression format |
H.264 |
|||
IP camera input |
9ch channel |
16ch channel |
25ch channel |
32ch channel |
Operation Mode |
live view, record, playback, backup, network |
|||
HDMI output |
1 channel, resolution: 1080P, 720P, 1440x900, 1280x1024, 1024x768,800x600 |
|||
VGA output |
1 channel, resolution: 1080P, 720P, 1440x900, 1280x1024, 1024x768,800x600 |
|||
Live view channel |
9ch 1080P simultaneously |
16ch D1 simultaneously |
25ch CIF or 9ch 1080P simultaneously |
32ch CIF or 9ch 1080P simultaneously |
Record channel |
9ch 1080P simultaneously |
16ch 1080P simultaneously |
25ch 1080P simultaneously |
32ch 1080P simultaneously |
Playback channel |
9ch 1080P simultaneously |
9ch 1080P or 16ch 720P simultaneously |
||
Record resolution |
3M/1080P/960P/720P/D1/HD1/CIF |
|||
Record model |
Manual/Schedule/Motion Detection/alarm |
|||
Record Search |
Time Point / Calendar / Event / Channel |
|||
Audio Input |
9ch IPC Composite Audio Input |
16ch |
25ch |
32ch |
Audio Output |
1CH, RCA (2.0Vp-p, 1KΩ) |
|||
Two-way Talk |
1 channel Input( Linear electrical levell , impedance : 1kΩ), 1 channel Output, RCA |
|||
Alarm Input |
9ch |
16ch |
||
Alarm Output |
4ch |
|||
Search method |
Time, Event, Channels and Calendar |
|||
Display Split |
1/4/9 channel |
1/4/9/16 channel |
1/4/9/16/25 channel |
1/4/9/16/25/36 channel |
NETWORK protocol |
TCP/IP,UDP,HTTP,DDNS,SMTP(SSL),LAN,DHCP,PPPOE, NTP, FTP, ARSP,WIFI, 3G |
|||
Network |
RJ45 10M / 100M/1000M adaptive Ethernet port |
|||
Backup |
HDD, USB Flash Disk |
|||
USB |
2*USB2.0 port, 1*USB3.0 |
|||
HDD |
8pcs SATA HDD, each port support max 4TB HDD |
|||
eSATA port |
support |
|||
Power supply |
ATX100~240V,50-60Hz |
|||
power consumption(without HDD) |
≤50W |
|||
Operation temperature |
0℃-+55℃ |
|||
Operation humidity |
10%-90% |
|||
Demension(W*D*H) |
440*447*90mm (2U case) |
|||
Weight(net/gross weight) |
6.1/7.5kg(without HDD) |
|||
