Paste Filling Machine(volume Type)

Paste Filling Machine(volume Type) thumbnail-1
Paste Filling Machine(volume Type) thumbnail-2
Paste Filling Machine(volume Type) thumbnail-3
Paste Filling Machine(volume Type) thumbnail-4
Paste Filling Machine(volume Type) photo-1
Paste Filling Machine(volume Type) photo-2
Paste Filling Machine(volume Type) photo-3
Paste Filling Machine(volume Type) photo-4
US$ 3,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Food, Medical, Medical, Other, Chemical, Food, Medical, Medical, cosmetic, medicine, pesticide, ink,etc.
Packaging Type:
Bags, Barrel, Bottles, Pouch
Contact Supplier Request Quote Chat Now
Shanghai Siehe Mechanical & Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Chemical, Food, Medical, Medical, Other, Chemical, Food, Medical, Medical, cosmetic, medicine, pesticide, ink,etc.
Packaging Type Bags, Barrel, Bottles, Pouch
Packaging Material Glass, Metal, Paper, Plastic, Wood
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 220V/50Hz, 380V/50Hz
Power customized
Place of Origin Shanghai, China
Brand Name SIEHE
Model Number SGZX Series
Dimension(L*W*H) depending
Weight Depends
Certification ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

Paste Filling Machine(volume type)



Product Description

Paste Filling machine (Volume Type) /Small Batch Paste Filling Machine adopt volumetric method to measure, through the way

adjust the plunger volume to realize the control of filling quantity.The reciprocating movement of the piston achieves filling

rapidly.The equipment has advantages of high filling efficiency and easy maintenance. Siehe Paste Filling Machine (volume

type) is widely used in industries such as coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fineness chemical

 etc.. It is suitable for the filling of both high,medium and low viscosity liquid.





     Paste Filling Machine(volume type)



Advantages

Filling quickly, wide application

Filling head can use single or double, piston working, high filling speed, cost savings, and reduce the workers’ work pressure;

It is suitable for round, square, flat and various diameter of filling. Unique valve body structure,realize multi-usage of paste,

adhesive, and liquid.



Convenient operation, easy maintenance

Pedal switch operation, convenient and practical,filling volume can can be adjust easily, the disassemble and clean

convenient, and the operation can be finished by one person, all equipped with imported components, so the quality is stable

and reliable.



Filling of high precision

Measuring mechanism adopts plunger method, filling volume precision, measurement error is less than ±1%.

Environmental protection index outstanding and safe;

Full pneumatic control, meet the requirements of explosion-proof.





Technical Parameter
