Laboratory Multi-functional Machine

Name: Laboratory Multi-functional Machine
Brand: Siehe
SKU: 100444571
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Siehe

Shanghai Siehe Mechanical & Electrical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name Siehe

Model Number SDYT

Application Other, liquid

Voltage 220v 50/60Hz

Power(W) 1100w

Dimension(L*W*H) 580*410*170

Certification CE certificate

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Laboratory multi-functional machine

Product Description

The lab machine is a newly developed lab machine with multi-function and with high performance. It consists of driving system

supporting system, control system, working components and auxiliary system. With the help of different working heads and optional

components, one machine can carry out different working modes including Disperser, Basket Mill, Emulsifier, Mixer, Mixing Mill to

provide more possibilities for lab application. High-quality components, high precision processing, intelligent HMI, all make work

easy and happy.

[Production capacity]: 0.2-5L

[Applicable Materials]: Good for all kinds of Materials (Not Ex-proof nor flammable materials) with viscosity less than 25000cps,

solid contents shall be less than 80% such as emulsion paint, industrial paint, water-borne ink etc..

Technical Parameter

Working mode	Voltage	Power (w)	Speed (rpm)	Working head	Capacity (water) (L)	Lifting
Disperser	220V 50HZ	1100	100-6000	dia 50mm, 80mm, 100mm (single layer) dia 80mm,100mm (double layer)	2.5L 5L	Electrical
Basket mill	220V 50HZ	1100	100-3000	The grinding cavity volume is 1L, with 0.6-2mm zirconium bead	2.5L 5L	Electrical
High shear Emulsifier	220V 50HZ	1100	100-6000	Two types of working heads, high shear and Up-flow type	2.5L 5L	Electrical
Vacuum dispersing mixer	220V 50HZ	1100	100-6000	Tooted type dispersing disc, butterfly agitator, and propeller agitator	2.5L	Electrical
Mixing Mill	220V 50HZ	1100	100-6000	One 60mm and one80mm polyamidegrinding wheel One 85mm stainless steel eccentric grinding wheel	1.5L	Electrical
