Paint High Speed Dispersing Machine
PRODUCT INTRODUCTION
High-speed Disperser (Hydraulic Lifting) has dispersing and mixing function, which used for mass production; Equipment with inverter has stepless speed, can operate for a long time. It has stable running and low noise; Mixing disc is easy to be replaced, and can change different forms of dispersing discs according to production technology;
Lifting structure adopts hydraulic cylinder as actuator, stable lifting, integrated hydraulic station, environmental and without leakage. It is an ideal grinding machine for materials with many varieties and many colors.
PRODUCT ADVANTAGES
- Higher efficiency, better quality
The Max. rotation speed can be up to 2930rpm (For bigger power, 1450rpm), linear velocity is over 20m/s, it can rapidly disperse the powder in the liquid evenly;. Due to the strong shearing force , the materials are dispersed evenly and form good suspension effect.
- Safe and easy operation
Adopt hydraulic cylinder as lifting actuator. Control the hydraulic up, stop, down through the oil pump, easy operation and stable. The dispersing disc is fixed to the main shaft with Hexagon socket-head cap screws, which can be disassembled and exchanged quickly, easy to clean. Different dispersing discs can be exchanged accordingly to production process to obtain optimized dispersing result. Different clamping types(Belt Clamping, Manual Rotation Clamping, Pneumatic Clamping) are optional to fix the tanks properly to prevent from accident due to the tank displacement during operation.
- Various installation mode
With compact structure, the machine can be floor type and platform type. Tank working with the mixer can be movable type or fixed type.
- Optional configuration
Different options are available such as explosion-proof type, closed type, multi-tanks type, with lifting cover type, co-axial type/dual-shaft type, mounted on kettle type, etc.. Material can be customized to be SS304 SS321 SS316L.
TECHNICAL PARAMETERS
Model |
Motor power (kw) |
Speed |
Disc Dia (mm) |
Material |
Capacity (L) |
Hydraulic power (kw) |
Lifting |
Weight |
SFSY-1.5 |
1.5 |
0-1450rpm |
120 |
Contact material is SS304 |
≤60 |
0.55 |
600 |
400 |
SFSY-4 |
4 |
0-1450rpm |
200 |
Contact material is SS304 |
≤200 |
0.55 |
900 |
600 |
SFSY-7.5 |
7.5 |
0-1450rpm |
230 |
Contact material is SS304 |
≤400 |
0.55 |
900 |
800 |
SFSY-11 |
11 |
0-1450rpm |
250 |
Contact material is SS304 |
≤500 |
0.55 |
900 |
1000 |
SFSY-15 |
15 |
0-1450rpm |
280 |
Contact material is SS304 |
≤700 |
0.55 |
900 |
1100 |
SFSY-18.5 |
18.5 |
0-1450rpm |
300 |
Contact material is SS304 |
≤800 |
0.75 |
1100 |
1300 |
SFSY-22 |
22 |
0-1450rpm |
350 |
Contact material is SS304 |
≤1000 |
0.75 |
1100 |
1400 |
SFSY-30 |
30 |
0-1450rpm |
400 |
Contact material is SS304 stainless steel |
≤1500 |
0.75 |
1100 |
1500 |
SFSY-37 |
37 |
0-1450rpm |
400 |
Contact material is SS304 |
≤2000 |
1.1 |
1600 |
1600 |
SFSY-45 |
45 |
0-1450rpm |
450 |
Contact material is SS304 |
≤2000 |
1.1 |
1600 |
1900 |
SFSY-55 |
55 |
0-1450rpm |
500 |
Contact material is SS304 |
≤2500 |
1.1 |
1600 |
2100 |
SFSY-75 |
75 |
0-1450rpm |
550 |
Contact material is SS304 |
≤4000 |
2.2 |
1800 |
2300 |
SFSY-90 |
90 |
0-950rpm |
600 |
Contact material is SS304 |
≤6000 |
2.2 |
1800 |
2600 |
SFSY-110 |
110 |
0-950rpm |
700 |
Contact material is SS304 |
≤8000 |
3 |
2100 |
3100 |
SFSY-132 |
132 |
0-950rpm |
800 |
Contact material is SS304 |
≤10000 |
3 |
2300 |
3600 |
