Closed/Vacuum high speed dispersing mixer
Vacuum High-speed Disperser is a functional machine developed based on the standard High-speed Disperser. A closed lid, with spring seal ring mounted in a milling groove of the cover flange, is completely closed with tank and ensures no air leakage under vacuum operation surroundings.
Vacuum pumps are option whose limited vacuum degree can be -0.0998mpa(20mbar). It shows excellent performance during special dispersing condition such as vacuum defoaming, vacuum charging, inert gases protection and etc.
Higher efficiency, better quality
The Max. rotation speed can be up to 2930rpm (For bigger power, 1450rpm), linear velocity is over 20m/s, it can rapidly disperse the powder in the liquid evenly; Due to its high shear forces, the material will be uniformly dispersed and formed a good suspension effect. Due to the strong shearing force , the materials are dispersed evenly and form good suspension effect.
Safer and higher environmental protection index
The device can be totally closed with the help of a closed lid and generate a high vacuum degree space, which contributes directly to avoid the solution volatilization. All the working condition can be supervised with the help of the sight glass with a lamp. In addition, sanitary manhole is valued for cleaning and charging materials.
Various installation ways
With compact structure, the machine can be floor type and platform type. Tank working with the mixer can be removable type or fixed type.
Customized Options
Different options are available such as explosion-proof type, closed type, multi-tanks type, with lifting cover type, co-axial type/dual-shaft type, mounted on kettle type, etc.. Material can be customized to be SS304 SS321 SS316L
model |
power(kw) |
speed |
disc dia. (mm) |
material |
capacity (L) |
hydraulic power (kw) |
lifting (mm) |
weight (kg) |
SFSM-1.5 |
1.5 |
0-1450rpm |
120 |
contacting part is SS304 |
≤60 |
0.55 |
600 |
500 |
SFSM-4 |
4 |
0-1450rpm |
200 |
contacting part is SS304 |
≤200 |
0.55 |
900 |
700 |
SFSM-7.5 |
7.5 |
0-1450rpm |
230 |
contacting part is SS304 |
≤400 |
0.55 |
900 |
900 |
SFSM-11 |
11 |
0-1450rpm |
250 |
contacting part is SS304 |
≤500 |
0.55 |
900 |
1100 |
SFSM-15 |
15 |
0-1450rpm |
280 |
contacting part is SS304 |
≤700 |
0.55 |
900 |
1200 |
SFSM-18.5 |
18.5 |
0-1450rpm |
300 |
contacting part is SS304 |
≤800 |
0.75 |
1100 |
1400 |
SFSM-22 |
22 |
0-1450rpm |
350 |
contacting part is SS304 |
≤1000 |
0.75 |
1100 |
1600 |
SFSM-30 |
30 |
0-1450rpm |
400 |
contacting part is SS304 |
≤1500 |
0.75 |
1100 |
1800 |
SFSM-37 |
37 |
0-1450rpm |
400 |
contacting part is SS304 |
≤2000 |
1.1 |
1600 |
2000 |
SFSM-45 |
45 |
0-1450rpm |
450 |
contacting part is SS304 |
≤2000 |
1.1 |
1600 |
2400 |
SFSM-55 |
55 |
0-1450rpm |
500 |
contacting part is SS304 |
≤2500 |
1.1 |
1600 |
2600 |
SFSM-75 |
75 |
0-1450rpm |
550 |
contacting part is SS304 |
≤4000 |
2.2 |
1800 |
2800 |
SFSM-90 |
90 |
0-950rpm |
600 |
contacting part is SS304 |
≤6000 |
2.2 |
1800 |
3200 |
SFSM-110 |
110 |
0-950rpm |
700 |
contacting part is SS304 |
≤8000 |
3 |
2100 |
3500 |
SFSM-132 |
132 |
0-950rpm |
800 |
contacting part is SS304 |
≤10000 |
3 |
2300 |
4000 |
