Pigment Paste Making Equipment for Middle - High Viscosity Materials
Pigment paste Making Equipment (Hydraulic Lifting) integrates High-speed Disperser and Low-speed strong Mixer into one machine.
Main Features
Hydraulic cylinder lift
Two independently driven agitators
Scrapers to remove materials from the interior vessel wall
Various agitators for selection: anchor type, frame type, vertical screw type, butterfly type, spiral type etc.
All the part contacting with materials is mirror polished for easy clean.
Technical Parameters
Model |
Capacity |
Mixing Power |
Mixing |
Dispersing power |
Dispersing Speed |
SYZ-200 |
200 |
1.5 |
85 |
3 |
0-1450 |
SYZ-300 |
300 |
2.5 |
61 |
4 |
0-1450 |
SYZ-500 |
500 |
3 |
61 |
7.5 |
0-1450 |
SYZ-800 |
800 |
4 |
52 |
11 |
0-1450 |
SYZ-1000 |
1000 |
5.5 |
52 |
15 |
0-1450 |
SYZ-2000 |
2000 |
7.5 |
41 |
22 |
0-1450 |
*Calculated as per water as medium
**Dependent on material viscosity
Options
Mixer can work with multiple mixing vessels
Mixing vessel can be jacketed for heating/cooling
Mixing vessel mounted on casters
Sight ports, inlet and outlet nozzles
Sensors to detect temperature, pressure etc.
Variable speed system
Vacuum and pressure design
PLC control
Explosion proof
Applications
Coating, paint, printing ink, dye, pigment, adhesive, construction material, pesticide, lubricant, electronic chemical
Custom designs are also available
SIEHE Industry----Mixing Experts on Liquid and Powder!
Please feel free to contact us for more details:
Tel: +86 21 52913185 ext 113
Fax: +86 21 52912822
Email: sales04 at
