Paint and Ink High Speed Dissolver (Platform Type)

Paint and Ink High Speed Dissolver (Platform Type) thumbnail-1
Paint and Ink High Speed Dissolver (Platform Type) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Other, dispersing disc
Product Type:
Paint
Contact Supplier Request Quote Chat Now
Shanghai Siehe Mechanical & Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Mixer Type Other, dispersing disc
Product Type Paint
Application Other, solid-liquid, liquid-liquid
Additional Capabilities Other, dispersing, dissolving, mixing
Place of Origin Shanghai, China
Brand Name Siehe
Model Number SFSF
Max. Loading Capacity 10000L
Voltage 380V/50HZ(can be customized)
Power(W) accordingly
Dimension(L*W*H) accordingly
Certification CE certificate
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

 High Speed Hydraulic Lifting Disperser(Platform Type)

Product Description



Platform type Highspeed Disperser (Hydraulic Lifting) is for dispersing and mixing materials with mass production . With inverter

 various speed control, can be used continuously for a long time, stable operation and low noise. The dispersing disc is easy

to be disassembled. Dispersing discs with different sizes and different design can be designed according to the production

 technology. The dispersing set is fixed on the kettle and can move up and down within certain range. It is an ideal machine for

 dispersing and mixing. It is also can be customized to be mounted on kettle type.



[Production Capacity]: 50-20,000L



[Application Materials]:Good for all kinds of slurries with viscosity less than 100,000cps, and solid content less than 80%,

such as emulsion paint, industrial paint, water-based ink, pesticide, adhesive and etc.

Technical Parameter



Model

Motor

Power

(kw)

 Speed

(rpm)



Disc Dia

(mm)

  Material

Capacity

 (L)

 hydraulic

power (kw)



Lift

 (mm)



Weight

(kg)

SFSF-7.5

7.5

0-1450

230

Material Contact SS304 Stainless steel

≤400

0.55

300

800

SFSF-11

11

0-1450

250

Material Contact SS304 Stainless Steel

≤500

0.55

300

1000

SFSF-15

15

0-1450

280

Material Contact SS304 Stainless Steel

≤700

0.55

350

1100

SFSF-  18.5

18.5

0-1450

300

Material Contact SS304 Stainless Steel

≤800

0.75

350

1300

SFSF-22

22

0-1450

350

Material Contact SS304 Stainless Steel

≤1000

0.75

400

1400

SFSF-30

30

0-1450

400

Material Contact SS304 Stainless Steel

≤1500

0.75

400

1500

SFSF-37

37

0-1450

400

Material Contact SS304 Stainless Steel

≤2000

1.1

500

1600

SFSF-45

45

0-1450

450

Material Contact SS304 Stainless Steel

≤2500

1.1

500

200

SFSF-55

55

0-1450

500

Material Contact SS304 Stainless Steel

≤3000

1.1

500

2100

SFSF-75

75

0-1450

550

Material Contact SS304 Stainless Steel

≤4000

2.2

600

2300

SFSF-90

90

0-950

600

Material Contact SS304 Stainless Steel

≤6000

2.2

600

2600

SFSF-110

110

0-950

700

Material Contact SS304 Stainless Steel

≤8000

3

700

3100

SFSF-132

132

0-950

800

Material Contact SS304 Stainless Steel

≤10000

3

800

3600



Remarks:
* The capacity is data based on materials with viscosity approx. 1000cps. The model selection shall be based on the data such

as the materials viscosity, density etc..

*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc., detailed

data is required for correct model selection.
* If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
