Dry Mortar Complete Production Line
Introduction:
Dry Mortar Complete Production line consists of raw materials storage tank, batching screw, batching hopper with load cell, Material charging device with Bag-breaking function, ground bucket elevator, mixer, silo for finished products, packing machine, dust-collector and steel structure etc.. Together with components for controlling, air source system, control system to realize smart production. SIEHE company has provided production lines for ordinary mortar such as Masonry mortar, thermal insulation mortar etc. and special mortar such as Adhesive mortar, sealant mortar etc. , The production line is with stable performance and high production efficiency, capacity ranging from 2-50T/h.
Features:
The system can be divided into tower type, steel structure with pressure convey and simple type according to the required production capacity. The control method of the equipment can be mechanical manual operation or PLC automatic operation. Convey method of the equipment includes mechanical convey and pneumatic convey. And small bag packing, T-bag packing, bulk truck packing for the finished products. The whole system is with compact layout, fast batching, dynamic module with high accuracy. It is also with de-dusting system to ensure good working environment.
Technical Parameter:
System Capacity: 2-50 T/h
Please consult with our sales engineers. They will provide you with a most reasonable scheme together with our application engineer.
2000L/Batch mixing production line configuration table
SN |
System name | Equipment specification | Material | Qty | power |
1 |
Elevating system |
Lifting hoist 1T excludes verification fee |
market |
1 set |
7.5Kw |
| 2 | Raw material storage system |
A/B material storage tank 50T including material pumping |
Q235 |
2 sets | |
C/D material storage tank 5T including ton bag feeding station |
Q235 |
2 sets |
|||
| 3 | Batching system | A/B/C/D material batching scale 2000Kg±1Kg |
Q235 | 1 set | |
A/B/C/D material batching screw |
Q235 | 4 sets | 7.5Kw | ||
Manual unpacking metering feeding hopper |
Q235 | 1 set | |||
Horizontal screw, vertical lifting equipment |
Q235 | 1 set | 11Kw | ||
| 4 | Mixing system | Main mixer SWDM-3000P |
Q235 | 1 set | 30Kw |
Manual feeding port |
Q235 | 1 set | |||
| 5 | Finished product storage system | Finished product bin 2500L |
Q235 | 1 set | |
| 6 | Packing system | Valve bag screw packing machine |
Q235 | 2 sets | 4Kw |
| 7 | Dust collector | Dust collecting area 48 m2 |
Q235 | 1 set | 4Kw |
| 8 | Equipment installation and maintenance platform | Install four floors of steel platform 2200*4000*6000 |
Q235 | 1 set | |
| 9 | Non-standard items | Connections between equipments etc |
State standard | 1 set | |
| 10 | Control system | Power cabinet operation platform and operating system software |
Schneider | 1 set | |
| 11 | Accessories | Cable, air pipe and wind pipe etc |
State standard | 1 set | |
12 |
Power and air supply system | With 60Kw power and 2m³/min air source | State standard | 1 set | |
13 |
Transportation and installation | Manufactured in Shanghai and transported to destination | State standard | 1 set |
