Powder Blending Complete Production Line
Introduction:
Powder Blending Complete Production Line mainly consists raw materials storage, material feeding system, weight measurement, mixing system, dust extraction system, packing system, control system and platform. It is widely used for powder blending in industries such as pharmacy, food, pesticide, metallurgy, building materials, feedstuff, rubber etc..
Features:
1. The load cell is from international famous brand. High precision measurement, analog signal output to realize automatic control of the whole production line.
2. Various mixing equipment are optional such as Plough Mixer, Ribbon Mixer, Non-gravity Mixer, Conical Mixer etc. to meet the requirement of mixing different products.
3. Various materials feeding methods are optional such as Vacuum materials feeding, pneumatic convey, bucket elevator, screw convey, pipeline-chain convey etc.. Reasonable solutions for different products and different transmission distance.
4. With dust extraction system to make the working place clean and environmental.
Technique parameter:
System Components |
Function |
Optional Equipment |
Raw Material Handling System |
Unpacking, Feeding |
Small bag feeding station, Ton bag feeding station |
Batching System |
Feeding |
Powder Part: screw feeding, vibrating feeding, belt feeding, rotary valve feeding |
Weighing |
Powder Part: Weighing Hopper, the batching generally used weighing gain method, or can use weighing loss method. |
|
Conveying System |
Conveying |
Meet the requirements of conveying within the equipment in the production line. Belt Conveyor, Bucket Elevator, Screw Conveyor, Pneumatic Conveying System, etc.. |
Storage System |
Storage |
Apply to raw materials and finished products, intermediate storage; There are: raw materials silo, finished product hopper, temporary storage hopper before mixing, finished products hopper after mixing, etc |
Mixing System |
Mixing |
Horizontal Non-gravity Mixer, Horizontal Plough Mixer, etc.. |
Packing System |
Packing |
Top Open Bag Packing Machine, Ton Bag Packing Machine, etc.. |
Electronic Control System |
Monitoring |
Control Circuit Built: Relay, PLC, PC-based, etc.. HMI: push button, digital type, etc.. CMCC control center, IMCC control center, industrial wireless technology (in development),etc.. |
Dust Collecting System |
Dust removal |
Cartridge dust collector, filter bag dust collector, relieve or clean the dust problem |
Steel structure |
Operation platform |
Provide steel structure equipment installation, equipment operation and maintenance of the platform. |
