Good Price Label Machine /manual Labeling Printer Mechanism

Name: Good Price Label Machine /manual Labeling Printer Mechanism
Brand: SINMARK
SKU: 100428035
Availability: InStock

US$ 20 - 50 MOQ: 12 Sets

Key Specifications

Products Status:

Stock

Type:

Other, Label Printer Mechanism

Style:

Black And White

Shanghai Dengyuan Information Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Other, Label Printer Mechanism

Style Black And White

Use Barcode Printer

Interface Type Other

Max Paper Size 82.5mm

Black Print Speed 150mm/s

Color Print Speed no

Brand Name SINMARK

Model Number SID

Place of Origin Shanghai, China

Good price label machine /manual labeling printer Mechanism

Product Description

3120TIII Label Printer Mechanisms features:

Parameters

3120TIII Label Printer Mechanisms specification:
Model: SID-3120TIII
Printing	Print method	Thermal dot line printing
	Dots per line	640dots
	Resolution	8 dots/mm
	Maximum print speed	150mm/sec
	Print width	80mm
	Paper width	25 ~ 82.5 mm max.
	Paper feed pitch	0.125mm
	Paper path	Straight
	Paper type	Continuous, black mark, sticker, etc
	Paper off mode	Peel off and tear off
Detection	Head temperature detection	Via a thermistor
	Platen position detection	Via a mechanical switch
	Out-of-paper detection	Via a photo interrupter
	Black mark detection	Via a photo interrupter
Power supply(V)	Logic power supply(VDD)	5V
Power supply(V)	Heater print voltage(VH)	24V
Peak current(A)	Head	15.03A (26.4V / 384dots)
Peak current(A)	Motor	0.50A
Service life	Pulse activation	100 million pulses or more
Service life	Abrasion resistance(KM)	150 km or more
Operating temperature range(No condensation)		-5°C to 50°C
Storage temperature range (No condensation)		-20°C to 60°C
Dimensions(excluding the lever and convex part)(width x depth x height)		128.8(W)X68.5(D)X80.6(H)mm
Mass		Approx. 435g
Print speed changes according to the processing speed of the controller and print pulse width.When printing equal to the print width is performed.Changing rate of average head resistance: 15% or less

* The above parameters are subject to change without prior notice.
