Good price P3 P4 P5 P6 P7.62 P10 indoor full color rental led display
1.LED display introduction
LED screen is composed of LED display modules, control systems, frame or cabinet to display information, content diverse and can be customized according to the actual situation in size.
2. Features :
1) indoor and outdoor display, rich content.
2) energy conservation, high reliability, long life.
3) light weight, easy installation.
4) highest performance and costless.
For more products, please check the following:
3. Product Parameters:
Item | LIYI-ID-P3SMD | LIYI-ID-P4SMD | LIYI-ID-P5SMD | LIYI-ID-P6SMD |
Pixel pitch | 3mm | 4mm | 5mm | 6mm |
Pixel density | 111111 dots/sqm | 62500 dots/sqm | 40000 dots/sqm | 27777 dots/sqm |
Pixel configuration | 1R1G1B(2121SMD) | 1R1G1B(2121SMD) | 1R1G1B(3528SMD) | 1R1G1B(3528SMD) |
Max brightness | 1300nit | 1200nit | 1800nit | 1500nit |
View angle(horizontal) | ±110° | ±110° | ±110° | ±110° |
Standard cabinet size | 576*576mm | 512*512mm | 640*640mm | 576*576mm |
Weight | 35KG/sqm | 35KG/sqm | 35KG/sqm | 35KG/sqm |
Cabinet resolution | 192*192 pixel | 128*128pixel | 128*128 pixel | 128*128 pixel |
Max power consumption | 1100W/sqm | 1000W/sqm | 900W/sqm | 800W/sqm |
AVE. consumption | 350W/sqm | 300W/sqm | ||
Drive Method | 1/16 scan, constant current | 1/8 scan, constant current | ||
Cabinet material | Steel (cold rolled iron) or Aluminum (optional) | |||
Gray scale | 65536 (16 bit) | |||
Colors | 16.7M | |||
Refresh rate | 3000HZ | |||
Frame rate | 60HZ | |||
Protection level | IP43 | |||
Malfunction dot rate | 0.1≤‰ | |||
Control mode | PC synchronous or asynchronous control(optional) | |||
Input voltage(AC) | AC90—240V | |||
Operation voltage | DC5V | |||
Operation temperature | -20~50℃ | |||
Operation humidity | 10%~90% | |||
MTBF | 1000h | |||
Life span | 100000h | |||
4. Product details for referance:
5.LED rental cabinet structure:
Aluminum Die-cast Rental Cabinet
6.LED display control mode:
Asynchronous control mode support U-disk port,Ethernet rj45 port, Serial Rs232 port, Wifi, 3G series. Support all languages and fresh animations.
Display content:text, picture, video and can receive signals such as TV, VCR,DVD etc.
7.Installation:
8. Applications:
The main application areas: stage, wedding show, exhibition hall, conferance room, church, activities, shopping centers, ticket hall, hotel, businesses, bank, transportation, Industry and Commerce.
1. Flightcase
Our quality
1.CE & Rohse passed
2. Two years warranty and all life technique support
Company Introduction
SHENZHEN LIYI OPTOELECTRONIC Co., Ltd is a Chinese high-tech optoelectronics display enterprise which specializes in the research, development, production, sales,construction and service of LED display since 2009. LIYI LED established strict quality control of LED components, LED display and the whole set of video systems, devoting to provide the most suitable indoor or outdoor display solutions from design, manufacturing, installation and maintenance.
Our main products: indoor and outdoor full color LED display, LED pharmacy cross,
LED single color moving sign display, LED display accessories.
Our products are widely used in pharmacy, telecommunications,financial securities, electricity, transportation, schools, hospitals, supermarkets, hotels, weather, real estate, sports, stage, restaurants, entertainment, theater, municipal advertising and government departments etc., and exported to Europe, Asia, North America…
1.What is DIP LED? What is SMD LED?
DIP LED are throught the DIP(Dual in-line package) technology,after soldering the led lamp's feet to stable it on the PCB .,so it names of DIP LED. It has high brightness and waterproof ,using for outdoor using
SMD led also named SMT(surface mounted technology),through the SMT technology encapsulating diode,solodering this lamp on the PCB board surface,should not plug the lamp feet to the PCB board,so it names SMD led moule, using for indoor.
2: What is a pixel?
The minimum luminous pixel LED display, with ordinary computer monitor, said the "pixel" the same meaning;
3: What is the pixel pitch (spacing)?
Another pixel distance from the center to the center of a pixel;
