outdoor pure green LED P16 pharmacie croix

standard wooden box

Specifications

1) Green pharmacie croix
2) Support many languages
3) Double side display
4) Wireless communication

led apotheek kruis

Led pharmacy sign Features



    Our Led pharmacy sign integrated with Optics, Electron, Mechanism, and Computer technology. Using novelty and special LED display method, based on the principle of energy efficient,Fully utilize the display efficiency of single color LED. The biggest feature of our Led pharmacy sign is utilizing cross display area,using single color and double color mixed way to show dynamic, word, time, date and temperature, to reach amazing display effect.



Main performance and features of our Led pharmacy sign:



•  Adopt novel LED display technology, display plane dynamic image in cross area.
• Image display equipment integrated with Optics, Electron, Mechanism, computer and wireless communication technology.
•  Adopt video grade double color LED, display images steadily, colorful and clearly
•  Display real-time content. Customer can deal with dynamic file on computer with the special software offered by us. Then send it to Remote controller led moving message display to show via wire or wireless communication way.



2. Remote controller led moving message display Working Process



Dynamic display content will be deal with by special software on computer, then will be send to Remote controller led moving message display via wire or wireless communication way. When Moving led display work, It will show static or dynamic content from computer. Our Moving led display can display static state picture, word, time, date, temperature, and also many kinds of enrichment and lively dynamic picture.







3. Technical Parameter



1) Outdoor waterproof Moving led display.



2) Pixel Pitch:10mm,12mm,14mm,16mm,20mm,25mm



3) Dimension: 530×530mm,626×626mm,690×690mm,722×722mm,818×818mm,



946×946mm,1010×1010mm,1250×1250mm,1044×1044mm



4) Frame Material: steel or Aluminum.



5) Display Color: single color, dual color, full color



6) Display Content: Animation,Graphics,Word,Time,Temperature



7) Languages: Software support in English, French, Spanish ,Greece and Italian.



8) Display Pixels: Each side 1280pixels, Double face, Total 2560 pixels



               Or each side 3072pixels, Double face, Total 6144 pixels



9) Viewing Angle: H120/ V45



10) Brightness:3500-5500nits



11) Communication: RF Wireless or RS232, RF Wireless MAX communication distance 800m.



12) Working voltage: AC 176—264V/47-63HZ



13)Working environment: Temperature -20°C - 70°C, Humidity 95 %



14)Life span: ≥50000hrs



15)Transportation caution: Anti-humidity,Anti-shake

  Picture :
