Help CenterLed Matrix Message Display
US$ 300 - 1,000
MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Liyi
Model Number:
Liyi-dot-8-8
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Led Moving Sign BoardUS$ 350 - 480MOQ: 1 Piece -
P16 Single Red Display a Led per EsterniUS$ 350 - 480MOQ: 1 Piece
-
Taxi Top Hyundai Vera Cruz Car GpsUS$ 300 - 600MOQ: 10 Pieces
-
P10 Outdoor Blue Led Signs China, Programmable Digital Led Sign BoardUS$ 300 - 870MOQ: 1 Piece
-
Led Car Top Sign Taix Top Sign Message SignUS$ 300 - 600MOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Liyi
Model Number
Liyi-dot-8-8
Usage
Semi-outdoor
Tube Chip Color
Green
Display Function
Video
Pixels
Other, 4.75 mm
Specifications
1. Color: Double color2. Pitch: 4.75mm
3. 8*8 DOT matrix
4. Long lifespan>100, 000 hours
5.Cabinet: Iron and Aluminum
Function and Technology characters of DOT Matrix Image Text Double Color LED Display:
1. Show all kinds of word, text, graph, pictures, flashes, video, 2-dimension, 3-dimension cartoon and any other formats with your PC does synchronously.
2. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL, DVI, AVI, VGA, SDI, MOV, MPG, etc.
3. Waterproof IP65 with sealed cabinets. Suitable for outdoor application in all kinds of weather condition.
4. It can be used in advertisement, stage, stadium, exhibition, TV-Show, mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc.
| Parameter | Dual Color | |
| Pixel | Pixel Diameter | 3.75mm |
| Pixel Pitch | 4.75mm | |
| Chip | Taiwan | |
| Color | 1R1G | |
| density | 44320 dots/sq. m | |
| Unit Board | Dimensions | 304mm× 125mm |
| Resolutions | W: 64 dots× H: 32 dots | |
| 2048dots/pcs | ||
| LED Display | Display Size | W: 2.736m m× H: 1.672m= 4.57m 2 |
| Quantity of Unit Board | W: 9× H: 11pcs= 99pcs | |
| Resolutions | W: 576 × H: 352dots=202, 752 dots | |
| Player Content | Image, Text | |
| Weight | 30kg/m 2 | |
| Thickness | 10cm | |
| Frame Structure | ATG Special Frame | |
| Power | Voltage | 220V/110V± 10% |
| Max Power Consumption | ≤ 240 W/m 2 | |
| Control System | Host | P4 and more |
| Control Type | Synchronous | |
| Operate System | WINDOWS 98 | |
| Main Tech | Module Spec. | 8× 8 dot matrix |
| Drive Device | LED Special Drive Device | |
| Drive Type | 1/16 Scan | |
| Refresh Rate | ≥ 120fps | |
| Frame Frequency | ≥ 60fps | |
| Brightness | ≥ 200cd/m 2 | |
| Brightness Adjustment | Software Adjustment | |
| Gray Scale | 256 levels | |
| Best Viewing Angle | ± 60 | |
| Best Viewing Distance | 5-40m | |
| effective communication distance | Less than 120m | |
| Working Temperature | -20-+60 degree Celsius | |
| Relative Humidity | ≤ 85% | |
| Software | LED general player software | |
