RV901H/921H/931H Single Color Tri Color Rgb Synchronous Control Receiving Card Led Display Controller

Name: RV901H/921H/931H Single Color Tri Color Rgb Synchronous Control Receiving Card Led Display Controller
Brand: LIYI
SKU: 100369805
Availability: InStock

RV901H/921H/931H Single Color Tri Color Rgb Synchronous Control Receiving Card Led Display Controller thumbnail-1

RV901H/921H/931H Single Color Tri Color Rgb Synchronous Control Receiving Card Led Display Controller thumbnail-2

RV901H/921H/931H Single Color Tri Color Rgb Synchronous Control Receiving Card Led Display Controller photo-1

RV901H/921H/931H Single Color Tri Color Rgb Synchronous Control Receiving Card Led Display Controller photo-2

US$ 20 - 350 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

LIYI

Model Number:

RV901

Contact Supplier Request Quote Chat Now

Shenzhen Liyi Optoelectronic Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name LIYI

Model Number RV901

Usage Other, indoor/semi-outdoor/outdoor

Tube Chip Color Other, single color/tri-color/full color

Display Function Other, animation/graphics/video

Pixels Other, p2.5 p3 p4 p4.75 p5 p6 p7.62 p8 p10 p16 p20 p25 p31.25

Screen Dimension 1024*256 pixels

Good Quality---Factory Price

More Details contact me

skype:liyisales03

RV901H/921H/931H single color tri color rgb synchronous control receiving card led display controller

1.Features and Parameters

RV901/911/921/931 is upgraded from the 8th generation system RV801. Compared with RV801, RV901 has all functions of RV801 and can replace RV801, besides, RV901 is added the following functionality:

1. support 12-bit HDMI colors input (required the 9th generation sending card)
2. using18-bit signal processor, maximum support 18-bit (260,000) gray (each of red, green and blue).
3. Single card maximum supports 1024X256 pixels, and 1024 grades single pixel chromaticity correction
4. Supports single-card color space conversion
5. Support configuration file readback
6. Support program replication
7. Supports hot backup with dual receiver cards for demanding performances screen
8. Supports pixel fault detection (requires a dedicated chip support)
9. Support network cable BER test
10. Support flat cable fault detection
11. Support the cabinet-door monitoring (open/close)
12. Two lines fan-speed monitoring
13. Three lines Voltage monitoring: one for the system, two for cabinet power
14. Temperature monitoring
15. Humidity monitoring (humidity sensor sold separately)
16. Smoke monitoring (smoke module sold separately)
17. In line with EU standards CE-EMC

2.Control Mode

3.Application Projects

4.Packing and shipping

-small quantity with carton boxes, big quantity with strengthen plywood boxes

-usually by Express,DHL,UPS,TNT,FEDEX; big quantity, air shipping available.

5.After-sale service

-2 years warranty

-if broken under warranty time,we will supply technical support or free spare parts to repair.
