SHEN ZHEN Pixel Pitch 16mm Led Display Sign

Name: SHEN ZHEN Pixel Pitch 16mm Led Display Sign
Brand: LIYI, LIYI
SKU: 100368469
Availability: InStock

US$ 500 - 2,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

LIYI, LIYI

Model Number:

LIYI-P16

Shenzhen Liyi Optoelectronic Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name LIYI, LIYI

Model Number LIYI-P16

Usage Outdoor

Tube Chip Color Full Color

Display Function Other, Video, Video-Text Message-Graphics-Animation

Pixels Other, 16mm, PH10, PH12, PH16, PH20, PH25,PH31.62

Screen Dimension 320*320mm

Specifications

1.High Resolution
2.High Brightness
3. 2 years warranty
4. factory price
5. CE&RHOS

Specification of Outdoor LED display
Classification	Ph10	Ph12	Ph14	Ph16	Ph18	Ph20	Ph22	Ph25	Ph31.25
Pixel pitch(mm)	10(physical)	12(physical)	14(physical)	16(physical)	18(physical)	20(physical)	22(physical)	25(physical)	31.25
Pixel pitch(mm)	10(physical)	6(virtual)	14(physical)	8(virtual)	18(physical)	10(virtual)	22(physical)	12.5(virtual)	31.25
Pixel configuration	1R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B	4R2G2B
LED package	DIP346	DIP346	DIP546	DIP546	DIP546	DIP546	DIP546	DIP546	DIP546
Pixel denstiy/ sqm	10000dots	6844dots	5102dots	3906dots	3086 dots	2500dots	2066dots	1600dots	1024dots
Pixel denstiy/ sqm	10000dots	27777 dots	5102dots	15625 dots	3086 dots	10000dots	2066dots	6400dots	1024dots
Module size(mm*mm)	320*160(h)	192*192(h)	224*112(h)	256*128(h)	288*144(h)	320*160(h)	352*176(h)	200*200(h)	125*250(h)
Module pixel( dots)	32*16	16*16	16*8	16*8	16*8	16*8	16*8	8*8	4*8
Standard size of cabinet(mm*mm)	1280*960	1152*768	896*896	1024*768	1152*864	1280*960	1056*1056	1000*1000	1000*1000
Cabinet pixel( dots)	128*96	96*64	64*64	64*48	64*48	64*48	48*48	40*40	32*32
Best view angle	110°	110°	110°	110°	110°	110°	110°	110°	110°
Maximum power comsuption(W/sqm)	750	700	600	1000	950	900	700	600	600
Brightness cd/sqm	≥8 000	≥8000	≥8000	≥ 7500	≥ 6500	≥ 60 00	≥ 5500	≥5000	≥ 5500
Driving method	1/4 constant driving		1/2 contant driving	Constant static
Display color	256256256
Refresh frequency	300HZ
Frame frequency	60HZ
Protection Level	Front: IP 65; back: IP43
Working Voltage	AC220/110±10%
Working environment temperature	-40º degree - +50º degree
Life span	>100000hours
