alphanumeric led display outdoor

standard wooden box

Specifications

1.outdoor advertising led display screen
2.very brightness
3.factory price
4.two years warranty
5. Life span 100,000 hours

Technical Parameters
1. LED chip size	red:9mil,green/blue:12mil
2. Pixel Pitch	20mm
3. Pixel Composition	2R/1G/1B
4. Pixel Density	10000(Dots/s.q.m)
5. Brightness	≥6500(CD/s.q.m)
6. View Angle	H:120°(+60/-60),V:60°(+30/-30)
7. Viewing Distance	≥20m
8. Gray scale (level)	4096
9. Refresh frequency	≥300HZ
10. Color temperature	6500K
11. Input voltage (AC)	110V~240V
12. Input power frequency (Hz)	50HZ~60HZ
13. Power Consumption	MAX:670(W/s.q.m),AVG.:230(W/s.q.m)
14. Control Mode	synchronous
15. Drive Mode	static scan constant current
16. Communication Interface	RJ45
17. Control distance	CAT5 cable:<100 m,Single fiber:<10 km
18. Signal input format (with video processor)	AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
19. Operating system	Windows (2000/XP/Vista/Win7)
20. Frame Material	Aluminum or steel(cold rolled)
21. Working Temperature(°C)	-10~+65(for working)
22. Working Humidity	10%~95%RH
23. Blind spot rate	<1/10000
24. IP grade	IP65
25. Life span	100,000 hours

P20 Outdoor full color LED display

Function and Technology Character

(1) Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
(2) 10 BIT grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chromic can be adjusted by manual and sensor, whose scope is 256 grade.
(3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
(4) Line-Double technology is adopted for the picture adjustment.
(5) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.
(6) Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof.

Display and control feature Structure feature
Specification Parameter Specification Parameter
Pixel Pitch 16 mm Module size 256 mm*128 mm
Pixel composing 2R1G1B Display resolution/module 16 dots*8 dots
Wavelength (R) 625± 5 Standard cabinet size 1024 mm*768 mm
Wavelength (G) 522± 3 Weight per sqm 65 Kg/sqm
Wavelength (B) 465± 5 Protection classification --- IP65
Wave Angle (H) 120° (H)/ 60° Install mode Wallmount, hung and stand structure

LED package DIP546
Density 3, 906 Working power
Display color 256*256*256 Specification Parameter
Whiteness brightness ≥ 5500CD Working voltage AC 220v/380v± 10% 47~64Hz
Brightness level 128 grade Max power/sqm 1600W/sqm
Changing frame frequency 60 Hz Average power/sqm 1100W/sqm
Refresh 400 Hz Short circuit protection Yes
Driving method Constant Static current
Control mode synchronous Working environment
Display port DVI Specification Parameter
Display mode 1024*768 /1024*1024 Environment Outdoor
Out of control 1/10, 000 ( scattered) Working temperature --20~50° C
Lifetime 100, 000 hours Working Humidity 10~90%.
