Unlock Universal LTE FDD B1/B3/B5/B7/B8/B20 4G USB WiFI dongle
| MANIN FUCTIONS: | |
| 1,Use modem and use wifi ,by set menu | Support |
| 2,Uplink 50Mbps,Downlink:150Mbps | Support |
| 3,SMS | Support |
| 4,USSD | Support |
| 5,Phonebook | Support |
| WIFI Fuction: | Support |
| 1,MAX WIFI Speed:150M | Support |
| 2,Internet connect share 5 user | Support |
| 3,WIFI Distance max 100M | Support |
| 4, HAVE MOBILE POWER ,CAN WORK | Support |
| SPECIFICATIONS: | |
| MAIN CHIPSET | QUALCOMM MSM9600 |
| 4G NETWORK | FDD-LTE: B1 2100 B3 1800 B7 2600 B8 900 B20 800 |
| WCDMA/HSDPA:2100MHz/900MHz; | |
| GSM/GPRS/EDEG:850 MHz/900 MHz/1800 MHz/1900 MHz | |
| 4G REQ | B1 SEND:1920-1980MHz RECEIVE:2110-2170MHz |
| B3 SEND:1710-178MHz RECEIVE:1805-1880MHz | |
| B7 SEND:2500-2570 MHz RECEIVE:2620-2690 MHz | |
| B8 SEND:880-915 MHz RECEIVE:925-960 MHz | |
| B20 SEND:832-862 MHz RECEIVE:791-821 MHz | |
| 4G DATA | WCDMA: DL:384Kbps,UP:384Kbps |
| DC-HSPA+:DL:42 Mbps DP:5.76Mbps | |
| FDD-LTE:DL:100Mbps DP:50Mbps | |
| ANTENNA | Built-in 3G&WIFI antenna WIFI Antenna Gain: -2dbi "WIFI Antenna Sensitivity: 54M:-68dBm PER<8% 11M:-84dBm PER<8% 6M:-88dBm PER<8% 1M:-90dBm PER<8%" 3G Antenna Gain: -2dbi |
| Power Consumption | Input Voltage: 5V/1A Output Voltage: 5V DC±10% Max Power consumption: <3W |
| WiFi Standard | 802.11b/g/n, speed upto 150Mbps |
| WiFi Security | 2412MHz-2472MHz |
| WiFi Security Mode | Open, WPA-PSK, WPA2-PSK |
| Working Temperature | -10 to 55°C |
| Working Humidity | 10%-85% RH |
| Storage Temperature | -20 to 70°C |
| Storage Humidity | 5%-90% RH |
We provide 4g modem with 12 months maintenance warranties.
Items can be replaced during the first month or maintained for the 1st year.
Buyers are only responsible for the return shipping fees for warranty items.
1.Reparing product:
We support one year warranty for our product and no charge for reparing the product.If our product have some problem within one year warranty and you send product to us and we will send to you after the reparing the product.It is free for shipping
back the product to you .
2.Question in using our product:
If you have some questions in using our product and please contact us anytime.We will answer you the question for free and if it is diffcult technology questions and we will asked our engineer and give you a satisfied reply.
3.Questions for shipping in the buying product:
We will calculate the total cost for you which generally contains the three part:
(1)The cost for the product you buy
(2)The cost for shipping to your country
(3)Poundage for the platform you use
4.If you want to go through our product and the follow is the link of our website:
