metal stamping mold
with coordinate measuring instrument
Product profile | |
Brand |
JR |
Origin |
Shenzhen city , Guangdong province , China(mainland) |
Certifacation |
ISO9001:2008 |
Capacity |
14+years R&D experience |
Feature |
EMD and OMD |
Product attibute(die detailes) | |
Product Name |
metal stamping mold using coordinate measuring machine/instrument |
Item |
Stamping Moulds/die/mold |
Material of Die |
D2, SKH-9, SKD11, A3 etc |
Design Software |
AutoCAD, PRO/E |
Die Type |
Stamping Moulds , stamping tools, progressive mold ,die casting mold , Terminal die,Single mold , double die or according to your parts |
Drawing format |
stp, prt, asm, pdf, dwg, dxf |
Die Life |
1,000,000-3,000,000 shots |
First Trial |
15 days after stamping moulds drawing confirmed |
Stamping mould cutting edge material |
Tungsten steel |
Quality guarantee |
you will confirm our stamping die quality according to sample. If you need to adjust the product structure, we can help you to change it further. |
Delivery |
Ship the stamping moulds after it is completely OK, packed as per customers' requirements |
The stamping die we produce can meet the demand of single sheet ,
automatic stacking , turn slots , 180 degree revolve , special pieces stacking , etc . And we lead the way to design hydraulic system , automatic rolling mold of DC motor iron drum and stretching mold for motor BB cover etc.
|
Main products (About mould) |
1.stamping part ( auto stamping part ,machinery stamping part ,electric appliance stamping part ,office equipment stamping part ); 2. compound part ( HDMI stamping part , IC chip Lead Frame , micro SD stamping part, PC terminal, I/O ,USB stamping part,etc) 3.precision stamping part ( terminal,c ontact ,connector ,flat spring , flat washer etc) deep drawing part ( stainless steel deep drawing part , aluminum stamping part , copper deep drawing part ,etc) 4.motor part( stator , rotor , motor core . motor case , motor body . motor bracket ,wound motor stator and rotor , alternator stator ,coating motor stator and rotor , etc) 5.stamping die( metal stamping die ,deep drawing die ,tranfer die , progressive die ,punching die ,forming die , bending die ,deep drawing die , high speed stamping die ,single die ,etc |
About testing instrument---
Three dimensional coordinate measuring insturmentIntroduction about coordinate measuring instrument
Three-dimensional coordinate measuring machine in the mold industry is quite extensive,
It is a design, development, testing, modern intelligent tools of statistical analysis,
Threedimensional coordinate instrument is an effective tool for mold product quality and technical safeguards.
Today the main use of the coordinate measuring machine Bridge measuring machine, gantry measuring machines, horizontal-arm measuring machine and portable measuring machines.
Species about coordinate measuring instrument
1 fixed table Cantilever coordinate measuring instrument
2 mobile bridge coordinate measuring instrument
3 gantry coordinate measuring instrument
4.L bridge type coordinate measuring instrument
5 fixed bridge coordinate measuring instrument
6 mobile workstations cantilever coordinate measuring instrument
7 column coordinate measuring instrument
8 horizontal arm coordinate measuring instrument
9 portable coordinate measuring instrument
In providing size data for process control at the same time, coordinate measuring machine can provide the factory product testing, customer quality testing, gauge testing, mold workpiece testing, and other additional properties .
Service during producing
1.we can offer the winding and coating , motor cover , motor bracket motor .
2.we can offer the install of every part
3.we offer the surface finish
Late Services
1 can send engineers to foreign for maintenance, assemble
2 provides mold polishing, repair assembly instructions, operating
3, can provide fifteen percent of accessories
|
Feature/Advantage u Small orders or samples are available u Experienced engineers to promise all the process u Team work to confirm everything runs smoothly u Dedicated staff consist of specialized sales andhighly skilled engineers u Special engineers to inspect the whole production |
Shenzhen Jiarun Precision Industry Co., Ltd | |||
Founded time |
1997 |
Registered Place |
Shenzhen |
Management Mode |
Production and serving model |
Whether OEM |
YES |
Factory Area |
3000m2 |
Company’s licence |
Business License for Legal Person |
Phone |
86-0755-23491191 86-0755-23490155 |
Fax |
86-0755-23490062 |
Company’s address |
Building No.2,North, Yanchuan north Industry district, Songgang Town, |
||
Product introduction | |
Main Market |
Every city of China, Southeast Asia, South America, Brazil, India |
Main customer |
Foreign, institutions in China ,Foreign enterprises , |
Main Products |
motor rotor and stator , motor bracket, shredder blade, alternator stator ,Computer, mobile phone connector terminals, motor core stamping mould. |
Main Service |
According to the customer's drawings for mould design ,development and manufacture. |
Manufacturing equipment |
1)Wire-cutting centre 2)CNC machine centre 3)Japan Sodick wire-cutting machine 4)Precisely grinding center 5)Taiwan CNC machine center |
Testing equipment |
1)UK IMS Three-coordinate measuring system 2)Switzerland TASA Multi-function altimeter 3)Quality control center |
Company Introduction |
We are professional with progressive die, stamping die. Tooling material is good quality. We could provide service all about precision sheet metal stamping dies including stamping die design, stamping die manufacturing, machining and trouble shooting of stamping dies. |
(metal stamping mold with coordinate measuring instrument )
Q1:Are you manufacturer?
A1: Yes , we are professional manufacturer of motor rotor and stator , stamping mould and hardware parts , having more than 14 years history.
Q2:What do you need to provide in order to get a quotation?
A: If you can provide product drawings or samples , we will give an accurate quotation.
Q3: Can I have samples for testing before ordering products?
A: Yes , we suggest that customers should have some samples for testing ,making sure the product can just meet your request .
Q4:Why should I choose you ?
A: We are a professional manufacturer , having more than 14 years experience in the mould/tool/die field . Our factory has obtained the ISO9001:2008 ahead of the peers . We have not only quality guarantee , but also we help customers design before producing and provide good after-sale service.
Q5:Which kind of equipments do you have ?
A: Japan Sodick wire-cutting machine ,
Switzerland TASA Multi-function altimeter ,
Taiwan CNC machine,
PG optical contour grinder ,
Large-scale punching machine etc.
Q6: How to guarantee the quality?
A: a)more than 14 years experience
b)ISO9001:2008
c)Japan , Germany , Taiwan technology and equipment
d)QC--Switzerland TASA Multi-function altimeter , UK IMS Three-coordinate measuring
System
Q7: What about the price ?
A: We only offer the reasonable price instead of high price . The product with different quality has
Different price
Q8: Where is you loading port ?
A: shekou
Q9:Can we type ourselves brand on it ?
A: Sure , you can .
SHOW
We are the professinal die/mold/mould/tool (set) maker , and we promise to provide you content stamping die/mould/mold
metal stamping mold with coordinate measuring instrument
