Help CenterActuator MVE210
Related Products
The MVE is a flexible electro-mechanical actuator for the control of two and three way globe valves in: Heating and Cooling systems, Air handling units, District Heating plants, Industrial Temperature Control systems. The MVE can be controlled either by a proportional (modulating) signal or by an increase/decrease (Floating) signal simply changing switch settings on the field. It is designed for an easy installation to any CONTROLLI flanged valve. Linkage kits are available for threaded valves as well as for valves of other manufacturers.
The Actuator has a fine resolution (500 steps on the full stroke range) for a very accurate fluid control and it is able to self-calibrate on a different stroke without the need of any user action. A Plug&Play function is available as well calibrating the actuator on the valve at the very first power-on only. The MVE implements an smart control algorithm with self diagnostic and alarm functionality in case of unexpected operation, feedback of alarms to the user is provided by LEDs (Green and Red) on the control board.
MVE is available with standard yoke and with a compact yoke for applications where compact dimensions are required and each version can be available with close-off force 600 N, 1000 N and 1500 N.
Electronic Fail Safe function are available on models MVE506R-MVE506SR and on MVE206R-MVE206SR.
MVE2.. - MVE2..S
MVE is also available with high voltage power supply 230Vac with the same functionality of the 24Vac/dc. MVE206-MVE210-MVE215 have a standard yoke suitable fro installation on all Controlli flanged valves 2F/3F. MVE206S-MVE210S-MVE215S have a compact yoke suitable fro installation on threaded valve 2/3TGB..F and VSB/VMB (with AG52).
