high strength basket strainer filtering water cartridge

      Basket filters Mainly adopts : SS304, 304 l, 316, 316 l stainless steel woven mesh,                mesh, stainless steel sintered wire mesh, sintered felt .

       Basket filters Main structure :by the takeover, barrel, filter basket, flange, flange cover          and fasteners, etc.

       Basket filter (oil filter) belong to the piping thick filter series, can also be used for gas or        other medium large particle filtering, installed on the pipeline to remove fluid in the larger            solid impurities, installed on the pipeline to remove large solid impurity in the fluid, the              machine equipment (including compressor, pump, etc.), the instrument can work normally        and operation, to achieve stable process, the role of guaranteeing production safety.

      Basket filter  main materials is : stainless steel perforated plate, stainless steel woven             mesh and sintered stainless steel mesh. Dimension and the filtration precision according to         customer specific requirements (special pressure, special diameter) for processing.

      Basket filter features:

        1) Stable performance,

       2) Carrying amount is high,

       3) Filtration precision accurate,

       4) High corrosion resistance,

       5) Not easy to damage,

       6) The pressure loss is small,

       7) The filter has big filter area,

       8) Easy to clean,

       9) The characteristics of long service life,

Product appearance size, filtration accuracy, filter area, under pressure, can construction according to customer's request.

Basket filter  scope of application:

1, chemical industry, petroleum and chemical production in weak corrosive materials, such as: water, oil, ammonia, hydrocarbons, etc.

2, chemical corrosion in the production of materials, such as: caustic soda, soda ash, thick dilute sulphuric acid, carbonic acid, hyaluronic acid, etc.

3, low temperature of cooling material, such as: liquid methane, ammonia, oxygen and various cooling agent.

4  health, food, pharmaceutical production materials, such as: beer, beverage, dairy products, syrup, etc.
