The main products include V-belt ,timming belt,ribbed belt,raw edge cogged v-belt,variable speed belt,etc which are used in the filed of automotive,truck,motocycle and industry agriculture,household appliance.
Welcome to contact us,we hope to bulid good cooperation with you.
The transmission of synchronous belt is a new transmission mode and transmits the dynamic torce by the meshing of the belt teeth and pulley, lt combines respective advantages of gear transmission,chain tramission and transmission.
| Structure |
No. |
Name |
Function |
Material |
1 |
Top Rubber | Protect the linling tensile member |
CR |
2 |
Tensile Member | Core material to pass the dynamic force |
Glass Filber |
3 |
Teeth Rubber | Protect the tensile member and maintain the shape of the rubber |
CR |
4 |
Teeth Fabric | Maintain the shape of the adhesive |
Elastic Fabric
|
Industrial synchronous belt
Industrial synchronous belt drive is a new transmission mode that use meshing between teeth of belt to have impetus to work.They can be used in textile industry, light industry, chemical industry, industry electrical appliances, machinery for transferring power.
Material:Chroprene Rubber(CR), Glass Fiber, Fabric or others (as customer's requirement)
Type:
There are two kinds of industrial synchronous belt: one-sided tooth industrial rubber synchronous belt anddouble-sided tooth industrial rubber synchronous belt.
There are two kinds of single-sided tooth industrial rubber synchronous belt: T tooth industrial rubber synchronous belt and Arc tooth industrial rubber synchronous belt.
The Dimension and Profile:
T tooth industrial rubber synchronous belt
Arc tooth industrial rubber synchronous belt
| Type | Pitch Pb(mm) | Tooth height ht(mm) | Belt thickness hs(mm) | Angle β° |
HTD |
2M | 2 | 0.75 | 1.36 |
| 3M | 3 | 1.17 | 2.4 | |
| 5M | 5 | 2.06 | 3.8 | |
| 8M | 8 | 3.36 | 6.00 | |
| 14M | 14 | 6.02 | 10.00 | |
| 20M | 20 | 8.4 | 13.20 | |
STPD/STS |
S2M | 2 | 0.76 | 1.36 |
| S3M | 3 | 1.14 | 2.20 | |
| S4.5M | 4.5 | 1.71 | 2.81 | |
| S5M | 5 | 1.91 | 3.4 | |
| S8M | 8 | 3.05 | 5.3 | |
| S14M | 14 | 5.3 | 10.2 | |
RPP/HPPD |
2M | 2 | 0.76 | 1.36 |
| 3M | 3 | 1.15 | 1.9 | |
| 5M | 5 | 1.95 | 3.5 | |
| 8M | 8 | 3.2 | 5.5 | |
| 14M | 14 | 6.00 | 10 |
Are you a trading company or manufacturer? |
We are manufacturer.
|
What kinds of products we supply? |
V-BELT,TIMING BELT,RIBBED BELT,TRANSMISSION BELT,WRAPPED BELT,RAW EDGE COGGED V BELT,ETC. |
Do you Accept OEM service? |
YES! |
What's your Delivery Time? |
1)generally the samples will be sent immediately by the air express in 5-7 days if the goods are in stock. |
2) Normally within 30 days, please confirm with us before order! | |
How you pack products? |
Plastic rope+Carton |
What's your available port of Shipment? |
Normally, ningbo Other ports available but you should afford extra charges. |
Can you provide sample? |
Yes, product samples are warmly welcomed. You only need to pay for the shipping cost. |
How to pay? |
We accept T/T, Western Union |
