The Product Details of 8.4 Inch Resisitive Touch Panel Display :
- 8.4 inch size.
- Custom service is available.
- Low cost solution, Low power consumption.
- Consistently accurate, fast touch response.
- It can adapt to adverse environmental conditions.
| Size | 8.4“ inch |
| Structure | Film + Glass |
| Connector | Pin 4 plug connector |
| Thickness | 1.4 ± 0.15 mm |
| Touch Media | Finger, Touch Pen, Glove |
| Type | 4 Wire Resistive Touch screen |
| Ratio | 4:3 |
| Resolution | 4096*4096 |
| Response Time | ≤ 10 ms |
| Supply Voltage | 5V DC; 35 mA |
| Transparent | ≤ 78% |
| Screen Resistance | X:100-500Ω Y:200-1000Ω |
| Insulation Resistance | ≥20MΩ(10V DC) |
| Pressure | 30-150g |
| Surface Hardness | 3H |
| Life Span | > 1,000,000 time knocking ; ≥ 100,000 time in paddling |
| Operating Temperature | — 10℃ ~ +60℃ |
| Storage Temperature | — 20℃ ~ +70℃ |
| Storage Humidity | 20 ~ 85% RH (except congeal fog) |
| Custom Service | Available |
The Packing of 8.4 Inch Resisitive Touch Panel Display :
Anti-Static Foam+Paper Card+Ragged Bag+Carton
The Delivery of 8.4 Inch Resisitive Touch Panel Display :
5 work days after your finish payment
The Payment Terms of 8.4 Inch Resisitive Touch Panel Display :
- Full payment before delivery.
- Prepay 30% as the deposite,T/T 70% the balance before delivery.
- Prepay 50% as the deposite and mould fee ,T/T the balance before delivery.
- Payment method can be nogotiated.
About Our Company
SHENZHEN CKINGWAY TECHNOLOGY CO., LTD
GUANGDONG, CHINA(MAINLAND)
ACCOUNT REGISTERED IN 2013
BUSINESS TYPE: MANUFACTURE, TRADING COMPANY
Website:
The FAQ of 8.4 Inch Resisitive Touch Panel Display :
1.Why Choose Ckingway?
1)Enough industrail experience and involved main markets all over the world.
2)Dedicated and professional sales team will offer you 24 hours online and immediate service.
3)Precise and advanced equipments.
4)High quality and sensitivity.
5)Many kinds of products with all size.
2. What can we do for you:
Custom service is available.
3.What is the lead time of the products?
Samples in stock will be sent within 3 days after payment.
Two to Four weeks for mass production.
4.Payment methods?
T/T and Western union etc.The details of our payment terms is showing above.
5.How long is the warranty period?
About Warranty: Usually 1 Year without damaged by people actions. It depends on different products.
6.What is the products application?
Widely used in instrument, handheld devices, industrial control, medical, automotive, smart home and other fields.
