Help CenterAcrylic Panel Mounted Flow Meter for Clean Water
Related Products
-
Flow Sensor Water 1GPM Flow Meter Acrylic Rotameter Panel Meter Quality ChoiceUS$ 7 - 8MOQ: 1 Set -
35L Water Flow Meter Acrylic Rotameter Panel Type FlowmeterUS$ 7.2 - 7.8MOQ: 1 Piece
-
20GPM Water Flow Meter Acrylic RotameterUS$ 7.2 - 7.8MOQ: 1 Set
-
70L Water Flow Meter Acrylic Rotameter Panel MeteUS$ 4 - 100MOQ: 1 Set
-
Water Flow Meter Acrylic Flow Meter Panel Type Flow MeterUS$ 6 - 8MOQ: 1 Set
1.Remark:
1).Working Pressure:≤1.5MPa
2).Operating Temperature:0~90 C
3).Accuracy:±4%
4).Body Material:Acrylic
5).Fitting Material:ABS or SS
6).Float Material:SS
7).O-ring Material:Silicon rubber
8).The fixed screw of center distance F is M6×11.
9).Customized specifications are available
2.Technical Parameters of LZM Series Panel Type Flow Meter
Moder |
GPM (Liquid) |
LPM (Liquid) |
Screw thread |
Accuracy |
Size(mm) |
|||||||
A |
B |
C |
D |
E |
F |
G |
H |
|||||
LZM- 10GPM |
1-10 |
5-35 |
ZG1"outside |
±4% |
236 |
45 |
208 |
45 |
30 |
101 |
35 |
165 |
LZM- 20GPM |
2-20 |
10-70 |
ZG1"outside |
±4% |
236 |
45 |
208 |
45 |
30 |
101 |
35 |
165 |
LZM- 35GPM |
5-35 |
10- 130 |
ZG1"outside |
±4% |
236 |
45 |
208 |
45 |
30 |
101 |
35 |
165 |
LZM- 40GPM |
4-40 |
15-150 |
ZG1"outside |
±4% |
236 |
45 |
208 |
45 |
30 |
101 |
35 |
165 |
3.Material of the Parts of LZM Series Panel Type Flow Meter
You and your colleague have time hope you visit our factory and make business together.
If you want know more about our products,pls let me know.Upon receiving your reply,I will give more details.
