Specifications
acrylic rotameter
1 Easy installation
2 highly visible scale
3 acrylic body
water flow rotameters&acrylic rotameter
Series LZW-M is a standard precision-machined acrylic flow meter for liquids or gases, has direct reading air and water scales and is available in either English or Metric scales.
The LZW-M flow meters can be configured with a control valve on the inlet or no valve at all; fittings and valve can be specified in either brass or stainless steel; O-rings can provided with Buna-N, Viton or other optional elastomers.
| The material and code of the parts of LZW-T Series Flow Meter | ||||
| With value | Value | Fitting | Float | O-ring |
| T- with O- No |
√1.Brass 2.SS |
1 ABS 2.PP 3.PVC 4.Brass √5.Brass chromeplate 6.SS |
√1.SS 2.Acrylic 3.Agate ball 4.PTFE |
√1-Silicon rubber 2-Fluorin rubber 3-Butyl |
Features
•Easy-to-read English or Metric Scales
• Threaded brass inserts for quick installation
• Easy disassembly and assembly for maintenance
• Durable one-piece clear acrylic construction
• Stable, easy-to-read float
• Superior quality
APPLICATIONS
Air sampling equipment aquaculture
Desalinization equipment
Gas analyzers
Medical systems
Photoprocessing equipment
Water treatment and distribution systems
Rotameter Advantages
• Relative low cost and ease of installation
• Robust and easy to maintain
• Applicable to liquids and gases
• No need for auxiliary power
• Eliminates Ex protection and electromagnetic compatibility issues
Rotameter Limitations
• Generally, variable area flow meters must be mounted vertically
• No output for data transmission
• Sensitive to changes in viscosity
• Sensitive to changes in temperature and pressure
Variable area meters or rotameters are well suited for a wide variety of liquid and gas applications, including monitoring chemical lines, flow in material-blending applications, filtration loading and makeup water for food & beverage plants.
