Home > Products > Intelligent Security System Touch Screen > Replacement 10.1 Inch LCD Screen Assembly
Replacement 10.1 Inch LCD Screen Assembly
- Shenzhen
- Credit Card
You May Like
-
1024*600 Graphic LCD Module with RGB Backlight
-
Cheap 6.95 Inch Display Screen for Security Monitoring System
-
Shenzhen Suppler CKINGWAY 5.6 Inch Resisitive touch panel display use for Security Monitoring System
-
Competitive Price 7 Inch Replacement Touch Screen Panel for Security Monitoring
-
OEM / ODM Factory Directly Sales CKINGWAY 5.6 inch LCD Resisitive touch Panel display for Security Monitoring
-
EXW Factory Directly Sale CKINGWAY 5.6 Inch Touch Panel Monitor for Security Monitoring System
Product Details
| Products Status | Stock | Screen Size | Other, 10.1'' | |
| Type | Other, Capacitive, Projection Capacitive Touch screen | Interface Type | USB | |
| Resolution | Other, 1024*600, 1024*600 | Brand Name | Ckingway | |
| Model Number | SC15024-10.1 | Place of Origin | Guangdong, China |
Product Description
The Product Details of Replacement 10.1 Inch LCD Screen Assembly:
- 10.1 inch size.
- Custom service is available.
- Low cost solution, Low power consumption.
- Consistently accurate, fast touch response.
- It can adapt to adverse environmental conditions.
| Size | 10.1 inch |
| Structure | PET + Glass |
| Connector | Pin 6 12C interface |
| Thickness | 1.4 ± 15 mm |
| Touch Media | Finger, Touch Pen |
| Type | Projection Capacitive Touch screen |
| Ratio | 16:9 |
| Resolution | 1024*600 |
| Response Time | ≤ 10 ms |
| Supply Voltage | 2.8 ~ 3.3 V DC |
| Transparent | ≥ 83% |
| Screen Resistance | / |
| Insulation Resistance | ≥20MΩ(10V DC) |
| Pressure | 10 g |
| Surface Hardness | 3H |
| Life Span | > 1,000,000 time knocking ; ≥ 100,000 time in paddling |
| Operating Temperature | — 20℃ ~ +70℃ |
| Storage Temperature | — 30℃ ~ +80℃ |
| Storage Humidity | 20 ~ 85% RH (except congeal fog) |
| Custom Service | Available |
The Packing of Replacement 10.1 Inch LCD Screen Assembly:
Anti-Static Foam+Paper Card+Ragged Bag+Carton
The Shipping of Replacement 10.1 Inch LCD Screen Assembly:
5 work days after your full payment.
About Our Company:
SHENZHEN CKINGWAY TECHNOLOGY CO., LTD
GUANGDONG, CHINA(MAINLAND)
ACCOUNT REGISTERED IN 2013
BUSINESS TYPE: MANUFACTURE, TRADING COMPANY
Ckingway Technology Limited is a professional manufacturer engaged in the research, development, production, sale and service of LCD. Ckingway with wellequipped testing facilities and strong technical force. We are located in Shenzhen and have convenient transportation access.
Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
Website:
About Warranty:
1 Year without damaged by people actions.
The FAQ of Replacement 10.1 Inch LCD Screen Assembly:
1.Why Choose Ckingway?
1)Enough industrail experience and involved main markets all over the world.
2)Dedicated and professional sales team will offer you 24 hours online and immediate service.
3)Precise and advanced equipments.
4)High quality and sensitivity.
5)Many kinds of products with all size.
2. What can we do for you:
Custom service is available.
3.What is the lead time of the products?
Samples in stock will be sent within 3 days after payment.
Two to Four weeks for mass production.
4.Payment methods?
T/T and Western union etc.The details of our payment terms is showing above.
5.How long is the warranty period?
Usually 1 Year without damaged by people actions. It depends on different products.
6.What is the products application?
Widely used in instrument, handheld devices, industrial control, medical, automotive, smart home and other fields.
