Home > Products > HYDAC filter > High efficiency hot sale replace 0165R010BN3HC hydac filter element for protect the oil pump and other hydraulic components
High efficiency hot sale replace 0165R010BN3HC hydac filter element for protect the oil pump and other hydraulic components
- tianjin China
- T/T L/C D/P D/A
You May Like
-
High quality hydac filter for air compressor filtration protection 0500D020BN3HC
-
Specializing production high performance fuel recovery 0160 series HYDAC 0160R010BN/HC hydraulic oil filter cartridge
-
Gold Supplier Most Advanced replacement hydraulic pump station and oil filter for 0500D020BN/HC hydac filter
-
Hydac filter 0060R005BH3HC cross replacement element
-
manufacturer recommend good quality domestic hydac filter 0060D003BN/HC population
-
Supply a series of HYDAC filter 0240D010BN/HC for
Product Details
| Place of Origin | Hebei, China | Brand Name | hydac | |
| Model Number | 0165R010BN3HC | After-sales Service Provided | Overseas service center available |
Product Description
Advantages
♦ Folding machine, imported composite filter increases filter effective filtration area, pollutant carrying capacity.
♦ The frames are made of thicker steel plate, to meet higher pressure requirements.
♦ Different filter media with different sealing materials, sealing firmly
♦ This filter is made from glass fiber/stainless wire mesh which imported from the USA, possessing the convenient draining, large circulation area, low pressure loss, simple structure, small volume, light weight, evenly filter material amd so on.
♦ The compatibility of the filter material is suitable for general hydraulic oil filter.
♦ The filter element is supported by the either side of the solid and strong stability of filter material, which comform with the verification of ISO3724/76 hydraulic oil flowing fatigue property.
Hydac elements
| Filter material | high quality glass fiber filter |
| Filtration precision | 1, 3, 6, 12, 25...um |
| filtering ratio | >=100 X |
| Structural strength | 1.0 Mpa, 1.0 Mpa, 2.0 Mpa,21.0 Mpa |
| Use scope | hydraulic and lubrication system pressure oil filter, used to filter the pollutants in the system, ensure the normal operation of the system |
| Feature | 1.Excellent performance 2.High filtration efficiency 3.Prompt Delivery 4.Simple structure,Top quality 5.Under ISO9001-2000 quality certificate 6.The best Craftsmanship 7.International Approvals 8..Pre air filter manufacturer 9.Low initial pressure drop |
| flow (SIZE): | Pressure | Pressure | filter ( PS --- Paper) |
030 ---- 30L / min 060 ---- 60L / min 0110 --- 110L / min 0140 --- 140L / min 0160 --- 160L / min 0240 --- 240L / min 0330 --- 330L / min 0480 --- 480L / min 0500 --- 500L / min 0660 --- 660L / min 0950 --- 950L / min 1300--1300L / min 2600--2600L / min 3900--3900L / min | D ---- high pressure, 100bar 210bar 420bar R ---- Low, 16bar 25bar 30bar DN ------ imitation products of other companies | 001 --- 1 003 --- 3 005 --- 5 010 --- 10 020 --- 20 025 --- 25 | V --- 4 + 4 sintered felt W --- metal mesh BN - β-micron N filter BH - β-micron filter H Y --- polyester filter |
Test Certification
♦ ISO 2941 Collapse & Burst Resistant
♦ ISO 2942 Material Compatibility with Fluids
♦ ISO 2943 Material Compatibility with Fluids
♦ ISO 3724 Flow Fatigue Characteristics
♦ ISO 3968 Pressure Drop vs. Flow Rate
♦ ISO 16889 Multi-pass Performance Testing
