Help CenterReplacement Hydac Hydraulic Filter 2600 R 010 BN4HC for Wind Turbine
Related Products
-
Cartridge Structure and New Condition Fiberglass Replacement Hydac Hydraulic Filter 0660R010BN4HCUS$ 5 - 100MOQ: 10 Pieces -
Return Series Corrision Resistance Hydac (oil) Element Replacement 0660D005VUS$ 10 - 200MOQ: 10 Pieces
-
Standard or Customzied Industrial Cartridge Filter With High Performance Replace 0160D020P Hydac Filter ElementUS$ 10 - 100MOQ: 5 Pieces
-
Manufacturer Direct Supply High Quality and High Efficient Hydraulic 2600R020BN3HC Hydac FilterUS$ 10 - 100MOQ: 5 Pieces
-
Manufacturer Supplies 0140D003BN3HC HYDAC Filter Cartridge ReplacementUS$ 10 - 100MOQ: 10 Pieces
Advantages
♦ Folding machine, imported composite filter increases filter effective filtration area, pollutant carrying capacity.
♦ The frames are made of thicker steel plate, to meet higher pressure requirements.
♦ Different filter media with different sealing materials, sealing firmly
♦ This filter is made from glass fiber/stainless wire mesh which imported from the USA, possessing the convenient draining, large circulation area, low pressure loss, simple structure, small volume, light weight, evenly filter material amd so on.
♦ The compatibility of the filter material is suitable for general hydraulic oil filter.
♦ The filter element is supported by the either side of the solid and strong stability of filter material, which comform with the verification of ISO3724/76 hydraulic oil flowing fatigue property.
Hydac elements
hydac series filter criteria Filter material: using high quality glass fiber filter material Filtration precision: from 1, 3, 6, 12, 25...Mu m
filtering ratio: >=100 X
Structural strength: 1.0 Mpa, 1.0 Mpa, 2.0 Mpa,21.0 Mpa
Use scope: used in hydraulic and lubrication system pressure oil filter,
used to filter the pollutants in the system, ensure the normal operation of the system.
filter models: 0240D020BN4HC
HYDAC industrial hydraulic filter No. Example:
| flow (SIZE): | Pressure | Pressure | filter ( PS --- Paper) |
|
030 ---- 30L / min 060 ---- 60L / min 0110 --- 110L / min 0140 --- 140L / min 0160 --- 160L / min 0240 --- 240L / min 0330 --- 330L / min 0480 --- 480L / min 0500 --- 500L / min 0660 --- 660L / min 0950 --- 950L / min 1300--1300L / min 2600--2600L / min 3900--3900L / min |
D ---- high pressure, 100bar 210bar 420bar R ---- Low, 16bar 25bar 30bar DN ------ imitation products of other companies |
001 --- 1 003 --- 3 005 --- 5 010 --- 10 020 --- 20 025 --- 25 |
V --- 4 + 4 sintered felt W --- metal mesh BN - β-micron N filter BH - β-micron filter H Y --- polyester filter |
Test Certification
♦ ISO 2941 Collapse & Burst Resistant
♦ ISO 2942 Material Compatibility with Fluids
♦ ISO 2943 Material Compatibility with Fluids
♦ ISO 3724 Flow Fatigue Characteristics
♦ ISO 3968 Pressure Drop vs. Flow Rate
♦ ISO 16889 Multi-pass Performance Testing
Hydraulic filter elements are widely applied to various industries
Factory show
Package and Transportantion
