Home > Products > Blister Packing Machine > High Performance Automatic Blister Packaging Machine for Auto Parts and Hardware
High Performance Automatic Blister Packaging Machine for Auto Parts and Hardware
- 30 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Hot Sale CE Approved China Manufactuere PVC and Paper Card Blister Packing Machine for Nipple
- High Frequency Clamshell Blister Pack Hardware Blister Automatic Packing Machine
- AUTO Toothbrush/Scissors/Battery/Solid Gum Paper-Plastic Blister Packing Machine Wholesale
- egg carton machine/carton box machine/paper box packing machine
- carton packing machine/bottle pack into paper box/bag in carton machine
- Perfume Fill Box Machine
Product Details
Condition: | New | Application: | Chemical, Commodity, Other, Medical, Chemical, Commodity, Machinery & Hardware, Medical | Automatic Grade: | Automatic |
Driven Type: | Pneumatic | Voltage: | 220v 380v | Power: | 1.5kw |
Place of Origin: | Shanghai, China | Brand Name: | SH Automatic Blister Packaging Machine | Model Number: | SH-500D Automatic Blister Packaging Machine |
Dimension(L*W*H): | 5800*1050*1850mm(L*W*H) | Weight: | 2100kg | Certification: | CE & SGS & ISO9001 |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
standard export wooden case package
(Automatic Blister Packaging Machine)
Product Description
High Performance Automatic Blister Packaging Machine for Auto Parts and Hardware
1. Brief Introduction
SH-500D High Performance Automatic Blister Packaging Machine for Auto Parts and Hardware has the feature of advanced technology, complete function, reasonable working process, easy operation, and convenient maintenance. The whole working process is full automatic, which can really save you a lot of labor cost. Moreover, the operation is very easy, you only need one staff to operate the PLC.
This machine is suitable for the blister card packing of battery, stationery, food, medical equipment, toys,hardware, electronics, auto parts, daily use product, cosmetic etc, such as the injector, solid gum, toy car,scissor, flashlight, battery, spark plug,lip stick, hook, shaver, pencil etc.
2. Parameters of the Machine
Blister Packing Machine | Automatic Blister Packaging Machine |
Model | SH-500D Automatic Blister Packaging Machine |
Maximum travel range | 40-200mm |
Maximum forming area | 480×200mm |
Standard forming depth | 40mm( can be customized) |
Cutting frequency(times/min) | 12-25 times/ minute |
Air pressure | 0.5-0.8Mpa |
Air flow | ≥0.5m3/min |
Total power | 380V 50Hz 10.5kW |
Main motor power | 1.5kW |
Overall dimension | 5800*1050*1850mm(L*W*H) |
Machine weight | 2100kg |
3. Machine Working Procedure
4. Samples
Company Profile
Profile
Incorporated in the year 2008, Shanghai Shenhu Packaging Machinery Equipment Co.,Ldt is a small and medium size manufacturer and exporter with a wide range of precision machineries. Our range of products includes tube(cream) filling machines, bottle(liquid) filling machines, cup filling machines,food packing machines, carton machine, vacuum packing machine, sealers and cappers etc.
Our company has achieved notable growth and has become a progressive supplier of new generation packaging machines in China. Steered by a futuristic vision, we invest judiciously in building resources and execute day to day business operations with higher level of professionalism and efficiency.
We are a market savvy company, with a customeroriented quality deliverance approach that guides us to provide customized packaging machinery for specific packaging processes. Our prime focus is to create maximum utility and offer value for money to our customers. Hence, we make every effort to understand client's business and accordingly procure machines that meet their specific requirement to the fullest. Our prime motive is to play a crucial role in assisting clients to expand their business profits.
Combining years of experience, we have made a strong presence in domestic market. In our endeavor to achieve complete customer satisfaction, we offer our clients products and services of quality that is second to none in the industry.
Industries We Serve
Our machines meet with the packaging requirement of industries such as Pharmaceutical,Cosmetics,Chemicals,Food and so on,
Quality
We are a quality concerned company with a sole objective to deliver best packaging machinery.These are quality certified manufacturing units, which follow industry defined standards in product engineering. Thus, the different types of packaging machines offered by us are in accordance with international standards of functionality and reliability. The machines are supplied to clients along with the warranty papers and operational and maintenance manuals. We ensure to deliver machines in absolute factory condition.
After Sale Service
In order to keep our machines working smoothly, we offer timely after sales services. For our after sales services, we have a team of servicing engineers and experts. Our effective and prompt after sales service keeps our machines working effectively for longer duration.
Why Us
Some of the prime advantages that we have in the industry are Wide range of product catering to various industries Modernized infrastructure equipped with state of the art machinery Regular improvement in our product range High end client satisfaction Qualified and well trained team of workforce Widespread client are all over the world.
We are not the best,but we want to be better!
