Paper Cup Machine With Ultrasonic Sealing|Paper Cup Making Machine

Paper Cup Machine With Ultrasonic Sealing|Paper Cup Making Machine thumbnail-1
Paper Cup Machine With Ultrasonic Sealing|Paper Cup Making Machine photo-1
US$ 1,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Paper Cup Machine
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Zhengzhou Longer Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port/Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Product Type Paper Cup Machine
Place of Origin Henan, China
Brand Name LONGER
Model Number LG
Voltage 380V
Power(W) 4800W
Dimension(L*W*H) 2.6m*1.22m*1.7m
Weight 1500kg
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Paper Cup Machine with Ultrasonic Sealing|Paper Cup Making Machine
1.easy to operate
2.high quality
3.high capacity

Paper Cup Machine with Ultrasonic Sealing|Paper Cup Making Machine



Introduction:



1. Paper cup bottom sealing by hot air station.

2. It is easy to make cups of different size by changing moulds.

3. Cup side sealing by ultrasonic.

4. Double PE coating paper cups for cold drink(ice cream cups)as well as hot drink.

5. With robotic arm and 3 pillar shafts each side.

6. With advanced bottom knurling system, this ensures the high quality of paper cups.

7. Sucker import from Taiwan, which can reach 100 million times’ life span.

8. Design with unique iron web guard cover, our machine is very good for heat dissipation and ensure the longer life span than others.





Paper Cup Size RANGE: 2.5 ~~12OZ

Speed: 45~~50pc/min

Paper cup top diameter:45mm ~~Max 85mm

Paper cup bottom diameter: Min 35mm~~Max 62mm

Paper cup height: Min 35mm~~Max 125mm

Raw material: 180~~280gsm, single or double PE coating paper

General power: 4.8 kw

Electricity: 380V 3 phases or 220V 1 phase

Weight: 1500kg

Measurement: 2.6m×1.22m×1.7m



























Paper Cup Machine with Ultrasonic Sealing|Paper Cup Making Machine
