Help CenterFRP Trench Drain, 3mm Thick Wall, 1000mm x 200mm, Boltless Connection, IP67 Waterproof Channel
Product Spotlights
Related Products
-
FRP Trench Drain, Free Technical Support, 24/7 After-Sales Service, Fast Delivery 7-15 Days, Standard CompliantNegotiableMOQ: 300 Square Meters -
FRP Trench Drain, Temperature Range -40°C to 80°C, Self-Cleaning Design, 0.5% Slope, Lightweight 2kg/mNegotiableMOQ: 300 Square Meters
-
FRP Trench Drain for Food Processing Plants, Smooth Interior, Non-Toxic, NSF/ANSI 61 CompliantNegotiableMOQ: 300 Square Meters
-
FRP Trench Drain, EN 1433 Compliant, 200mm Depth, Heavy Duty, Chemical Resistant for Industrial UseNegotiableMOQ: 300 Square Meters
-
Structural GRP Pultruded Profiles in L, Z, U, C Shapes for Drainage BeamsNegotiableMOQ: 1 Set
As a leading manufacturer from Hengshui Ruibin New Materials LLC (established in 2019, ISO9001 certified), we are proud to introduce our premium FRP Trench Drain – 3mm Thick Wall, 1000mm x 200mm, Boltless Connection, IP67 Waterproof Channel. This high-performance drainage solution is engineered to deliver superior durability, corrosion resistance, and easy installation, making it an ideal choice for industrial, commercial, and municipal drainage projects. With a factory spanning 1,000–3,000 square meters and a skilled team of 101–200 employees, we ensure consistent quality and timely delivery to global markets.
Our FRP trench drain incorporates advanced fiberglass reinforced plastic (FRP) technology, offering exceptional strength-to-weight ratio and long service life. The 3mm thick wall provides robust structural integrity, while the boltless connection design simplifies assembly and reduces maintenance. Rated IP67 waterproof, this channel prevents water ingress and leakage, protecting the surrounding infrastructure from moisture damage. Whether you need a reliable drainage system for parking lots, warehouses, airports, or municipal roads, this product delivers consistent performance even in harsh environments.
Key Features & Benefits:
- Boltless Connection: Eliminates the need for bolts and fasteners, reducing installation time by up to 40% and lowering labor costs. The interlocking design ensures a secure, leak-proof joint.
- 3mm Thick Wall: Provides excellent load-bearing capacity and resistance to impact, suitable for heavy-duty applications (e.g., forklift traffic, pedestrian zones).
- IP67 Waterproof Rating: Fully sealed against water immersion up to 1 meter depth for 30 minutes, ideal for areas with high water flow or frequent cleaning.
- Corrosion & Chemical Resistance: FRP material withstands acids, alkalis, salts, and UV radiation, making it perfect for industrial plants, chemical facilities, and coastal regions.
- Lightweight & Easy to Handle: Approximately 60% lighter than traditional concrete or metal channels, reducing transportation and installation effort.
- Low Maintenance: Smooth inner surface minimizes debris accumulation and clogging; easy to clean with water or mild detergents.
- Customizable Sizes & Colors: Available in various lengths, widths, and colors (including RAL codes) to match specific project requirements.
Technical Specifications:
| Parameter | Value |
| Material | Fiberglass Reinforced Plastic (FRP) |
| Wall Thickness | 3 mm |
| Overall Dimensions | 1000 mm (L) x 200 mm (W) x 200 mm (H) (approx.) |
| Connection Type | Boltless (snap-fit / interlocking) |
| Waterproof Rating | IP67 (complete protection against dust and temporary immersion) |
| Load Class | A15, B125, C250 (optional, depending on grating) |
| Operating Temperature | -40°C to +80°C |
| Color | Gray, Black, or Custom (RAL) |
| Standard Compliance | ISO9001, ISO9000 |
The FRP Trench Drain is designed for optimal hydraulic efficiency. The internal channel profile ensures smooth water flow with minimal resistance, and the integrated slope (optional) can be tailored to your drainage requirements. The boltless connection not only speeds up installation but also allows for easy disassembly and reconfiguration if needed. Each section is precision-molded to ensure consistent dimensions and tight seals.
Compared to traditional concrete channels, our FRP version is significantly lighter, reducing shipping costs and on-site handling. The 3mm wall thickness provides excellent rigidity without adding unnecessary weight. The IP67 waterproofing is achieved through a specialized gasket system, ensuring that joints remain watertight even under pressure. This product is also resistant to UV degradation, so it can be used in outdoor applications without discoloration or brittleness.
Trust & Reliability:
Hengshui Ruibin New Materials LLC has been a trusted manufacturer since 2019, with an annual export value of US$2.5 Million – US$5 Million. Our factory utilizes advanced production lines and strict quality control procedures to ensure every channel meets the highest standards. We have successfully supplied products to markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our team of 101–200 skilled workers is dedicated to continuous improvement and customer satisfaction. With ISO9001/ISO9000 certification, we guarantee consistent quality and traceability.
We understand that drainage systems are critical infrastructure – that’s why we offer comprehensive technical support, including installation guidance, load calculations, and custom design services. Our product is backed by rigorous testing and field-proven performance. Whether you need a standard 1000mm x 200mm channel or a customized solution, we are ready to assist. Contact us today for a quote or sample request – experience the reliability and efficiency of our FRP trench drain firsthand.
Frequently Asked Questions (FAQ):
Q1: What is the load capacity of this FRP trench drain?
A1: The load capacity depends on the grating used. Our FRP channel itself can be combined with various gratings to achieve load classes A15 (pedestrian), B125 (light traffic), or C250 (heavy traffic). Please contact us with your specific load requirements for a recommendation.
Q2: How is the boltless connection sealed to prevent leaks?
A2: Each channel section features a precision-molded interlocking joint with an integrated EPDM gasket. When snapped together, the gasket compresses to create a watertight seal that meets IP67 standards. No additional sealant is required.
Q3: Can this drain be used in chemical or acidic environments?
A3: Yes, FRP is highly resistant to a wide range of chemicals, including acids, alkalis, and salts. It is commonly used in chemical plants, plating facilities, and waste treatment areas. For specific chemical compatibility, please provide the chemical concentration and temperature for a detailed assessment.
Q4: What is the typical installation process?
A4: The boltless design allows for quick assembly: simply align the sections and push them together until they click. The channel can be placed on a prepared concrete base or compacted gravel. Grates are then snapped into the top. Complete installation instructions are provided with each order.
Q5: Do you offer custom lengths or widths?
A5: Yes, we can customize dimensions, wall thickness, and color to meet project specifications. Minimum order quantity may apply. Please contact our sales team with your requirements.
Q6: Is this product UV-resistant for outdoor use?
A6: Yes, the FRP material is formulated with UV stabilizers to prevent yellowing and degradation from prolonged sun exposure. It is suitable for outdoor installations in all climates.
Q7: How do I clean and maintain the channel?
A7: The smooth inner surface resists debris buildup. Routine cleaning can be done by flushing with water or using a mild detergent. For heavy sludge, the grates can be removed for easy access. No special maintenance is required.
For more information or to request a sample, please contact Hengshui Ruibin New Materials LLC. We look forward to partnering with you for your drainage needs.
