Help CenterFiberglass Drainage Channel, 2000mm Long, Temperature Range -40°C to 120°C, Corrosion Proof
Product Spotlights
Related Products
-
Fiberglass Drainage Channel With 2-Year Warranty and Technical Support, CustomizableNegotiableMOQ: 300 Square Meters -
Fiberglass Drainage Channel Factory Direct, Free Sample Available, Fast DeliveryNegotiableMOQ: 300 Square Meters
-
Fiberglass Drainage Channel for Industrial Plant Floor Drainage, Chemical ResistantNegotiableMOQ: 300 Square Meters
-
FRP Drainage Channel With Anti-Slip Surface, UV Stabilized, Dimension 300x150mmNegotiableMOQ: 300 Square Meters
-
Fiberglass Drainage Channel With Load Class C250 and 1000mm Length for Heavy Duty ApplicationsNegotiableMOQ: 300 Square Meters
Hengshui Ruibin New Materials LLC, a professional manufacturer founded in 2019 with a 1,000-3,000 sqm factory and over 100 experienced employees, proudly presents our Fiberglass Drainage Channel – a 2000mm long, corrosion-proof solution designed for demanding environments. Engineered to withstand extreme temperatures from -40°C to 120°C, this drainage channel offers exceptional durability and chemical resistance, making it ideal for industries where metal or concrete alternatives fail. Our commitment to quality is backed by ISO9001 certification and a proven export track record to over 20 global markets.
This product is crafted from high-quality fiberglass reinforced plastic (FRP) using advanced pultrusion and molding techniques. The result is a lightweight yet structurally strong channel that resists rust, rot, and chemical attack. Below we detail the key features, technical specifications, and benefits that set our drainage channel apart.
Key Features & Technical Specifications
| Parameter | Value |
|---|---|
| Length | 2000 mm (standard), custom lengths available |
| Material | Fiberglass Reinforced Plastic (FRP) – isophthalic polyester resin |
| Temperature Range | -40°C to +120°C |
| Corrosion Resistance | Excellent against acids, alkalis, salts, solvents (contact for specific chemical compatibility) |
| Load Rating | Customizable: A15 (pedestrian), B125 (light vehicle), C250 (medium traffic), up to E600 (heavy duty) |
| Color | Standard gray (RAL 7032), other colors available on request |
| Surface Finish | Smooth interior for efficient flow; anti-slip top surface option |
| Weight | Approx. 10 kg per channel (2000mm) – lightweight for easy handling |
Product Advantages & Customer Benefits
- Superior Corrosion Resistance: Unlike steel or concrete, FRP does not rust or spall. It withstands aggressive chemicals, making it ideal for chemical plants, plating facilities, and wastewater treatment.
- Wide Temperature Tolerance: The -40°C to 120°C range ensures reliable performance in freezing climates and high-temperature industrial processes.
- Lightweight & Easy Installation: At about 10 kg per 2-meter section, one person can handle installation. Simple male-female joint system reduces assembly time.
- Customizable Load Capacity: Choose from multiple load classes to match your traffic requirements – from pedestrian walkways to heavy forklift zones.
- Low Maintenance: Smooth, non-porous surface prevents debris buildup and is easy to clean. No need for painting or coating.
- Long Service Life: FRP has a lifespan of 30+ years under normal conditions, significantly reducing replacement costs.
- Environmentally Friendly: Manufactured with low VOC emissions, and the material is recyclable at end of life.
Typical Applications
- Industrial drainage in chemical processing, electroplating, and food & beverage plants
- Municipal drainage systems (sidewalks, parks, parking lots)
- Agricultural drainage (livestock, greenhouse)
- Marine and offshore platforms requiring saltwater resistance
- Commercial kitchens and wash-down areas
Our factory in Hengshui, Hebei, China covers 1,000-3,000 square meters and employs over 100 skilled workers. We have achieved ISO9001 and ISO9000 certifications, ensuring consistent quality control throughout production. Since 2019, our annual export value has reached US$2.5 Million – US$5 Million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We ship from the ports of Tianjin and Qingdao, with reliable logistics partners to ensure timely delivery.
We understand that every project has unique requirements. That's why we offer flexible customization options: channel length, load rating, color, grating type, and even integration with pipe outlets. Our technical team is ready to provide drawings and load calculations upon request. With a strong commitment to customer satisfaction, we provide responsive after-sales support, including installation guidance and technical troubleshooting.
Choose Hengshui Ruibin New Materials LLC as your trusted partner for corrosion-proof drainage solutions. Our Fiberglass Drainage Channel combines durability, performance, and value – backed by a manufacturer with proven global experience. Contact us today for a quote or sample request. Let us help you solve your drainage challenges with high-quality FRP products.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum load this channel can handle?
A: The load rating is customizable. We offer classes from A15 (pedestrian) up to E600 (heavy industrial). Please specify your traffic conditions when ordering. -
Q: Can I get a different length than 2000mm?
A: Yes, we can manufacture channels in custom lengths (e.g., 1000mm, 1500mm, 3000mm) to fit your project. Lead time may vary. -
Q: Is this product resistant to UV radiation?
A: Standard FRP has good UV resistance. For extended outdoor exposure, we can add UV stabilizers or a gel coat. Please inquire. -
Q: How do I connect multiple sections together?
A: Each channel has a male-female end joint. Apply compatible adhesive/sealant and simply push together. We provide installation instructions. -
Q: What chemicals can it withstand?
A: It is resistant to most acids, alkalis, and salts. For specific chemical compatibility (e.g., sulfuric acid, sodium hydroxide), please provide concentration and temperature, and we will advise. -
Q: Does it come with a grate?
A: We offer matching FRP or stainless steel grates in various slot patterns. They are sold separately. Please contact us for options. -
Q: What is the typical lead time?
A: For standard 2000mm channels, lead time is around 15-20 days after order confirmation. Custom orders may take 20-30 days. -
Q: Is fire resistance available?
A: Yes, we can incorporate fire-retardant additives to meet certain flame spread ratings (e.g., UL94 V-0). Discuss your requirements with our sales team.
