Help Center50mm Length FRP U Channel, 2mm Wall Thickness, High Strength to Weight Ratio, Corrosion Resistant
Product Spotlights
Related Products
-
FRP U Channel 50mm x 25mm x 3mm With 1.8g/cm³ Density and UL94 V-0 Flame Retardant for Electrical EnclosuresNegotiableMOQ: 300 Square Meters -
Pultruded FRP U Channel 100mm x 50mm x 6mm, 30% Glass Fiber, Heat Resistant to 200°C, Corrosion ResistantNegotiableMOQ: 300 Square Meters
-
Custom FRP U Channel Size Options With 0.5mm to 10mm Thickness, UV Stabilized, Low Moisture AbsorptionNegotiableMOQ: 300 Square Meters
-
FRP U Channel 80mm x 40mm x 4mm, Pultrusion Process, High Strength, Non-Conductive, for Solar Panel MountingNegotiableMOQ: 300 Square Meters
-
FRP U Channel for Cable Tray Systems, Corrosion Resistant, Lightweight, 50mm x 25mm x 3mm, Easy InstallationNegotiableMOQ: 300 Square Meters
Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019, proudly presents our 50mm Length FRP U Channel with 2mm Wall Thickness. As a dedicated producer with a factory spanning 1,000-3,000 square meters and a team of 101-200 experienced employees, we are committed to delivering high-quality, reliable FRP solutions. This U channel is engineered to offer an exceptional strength-to-weight ratio while providing outstanding corrosion resistance, making it an ideal choice for demanding applications in construction, infrastructure, and electrical industries. Our annual export value of US$2.5-5 million and global market presence across North America, South America, Europe, and Asia underscore our capability to meet international standards.
The FRP (Fiber Reinforced Polymer) U channel is manufactured using a pultrusion process, ensuring consistent quality and dimensional accuracy. With a length of 50mm and a wall thickness of 2mm, this profile is compact yet robust. It is designed to replace traditional materials like steel and aluminum in environments where corrosion and weight are critical factors. The inherent properties of FRP—non-conductive, non-magnetic, and thermally insulating—add further value to your projects.
Key Features & Technical Specifications
- High Strength-to-Weight Ratio: Up to 5 times lighter than steel while maintaining comparable tensile strength, reducing structural load and installation costs.
- Superior Corrosion Resistance: Impervious to moisture, chemicals, salt spray, and UV degradation (with UV inhibitor additive), ensuring long service life even in harsh environments.
- Electrical Insulation: Non-conductive, making it safe for use in electrical enclosures, cable trays, and substations.
- Low Thermal Conductivity: Reduces heat transfer, suitable for thermal break applications.
- Customizable Dimensions: Width and color can be tailored to your specific requirements (contact us for options).
- Flame Retardant Option: Available with additives to meet specific fire safety standards (upon request).
| Parameter | Value |
|---|---|
| Length | 50mm (standard) |
| Wall Thickness | 2mm |
| Width (Flange) | Customizable (e.g., 30mm, 40mm) |
| Tensile Strength (typical) | ≥300 MPa |
| Flexural Modulus | ≥20 GPa |
| Density | 1.8 – 2.0 g/cm³ |
| Operating Temperature | -40°C to +80°C (higher with special resin) |
| Color | Gray (standard), custom colors available |
Benefits for Your Application
- Reduced Maintenance: Unlike steel, FRP does not rust or corrode, eliminating the need for painting or protective coatings.
- Lower Installation Costs: Lightweight design reduces labor and equipment requirements, and allows for faster assembly.
- Enhanced Safety: Non-conductive and non-slip surface options improve workplace safety, especially in electrical and wet environments.
- Design Flexibility: The 50mm length and 2mm wall thickness are ideal for small brackets, supports, and channeling systems where space is limited.
- Longevity: Resistant to chemical attack, moisture, and UV, ensuring decades of reliable performance with minimal degradation.
At Hengshui Ruibin New Materials LLC, we understand the importance of quality and consistency. Our factory is ISO9001:2015 and ISO9000 certified, ensuring that every batch of FRP U channels meets rigorous quality control standards. With a dedicated team of over 100 employees and a robust supply chain, we can handle both small trials and large-volume orders efficiently. Our main markets span the globe, including North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. We ship from the Port of Tianjin or Port of Qingdao, providing reliable logistics to our international customers.
If you are looking for a durable, lightweight, and corrosion-resistant material for your next project, our 50mm FRP U Channel is the perfect solution. We invite you to contact us for samples, customized dimensions, or bulk pricing. Our experienced sales team is ready to assist you with technical data and product recommendations. Choose Hengshui Ruibin – your trusted partner in FRP innovation.
Frequently Asked Questions (FAQ)
-
Q: What is the exact length of the U channel?
A: The standard length is 50mm. However, we can produce custom lengths per your request, typically up to 6 meters. -
Q: Can I get different colors?
A: Yes, the standard color is gray, but we offer custom colors (e.g., safety yellow, black) for minimum order quantities. Please inquire. -
Q: Is this product UV resistant?
A: Yes, our standard formulation includes a UV inhibitor to protect against sunlight degradation. For extreme UV exposure, we recommend a UV-stable resin. -
Q: What is the maximum operating temperature?
A: The standard grade can operate between -40°C and +80°C. For higher temperature applications (up to 150°C), we can use special resin systems – please contact us. -
Q: Is the FRP U channel flame retardant?
A: It is self-extinguishing by default. If you require specific fire ratings (e.g., UL94), we can add flame retardant additives – these options are available upon request. -
Q: How do I install this channel?
A: The FRP U channel can be cut, drilled, and fastened using standard tools. We recommend using stainless steel or FRP fasteners to avoid galvanic corrosion. Detailed installation guidelines are available. -
Q: Do you provide free samples?
A: Yes, we offer free samples for qualified inquiries. Please contact our sales team with your shipping details and intended application. -
Q: What is the minimum order quantity (MOQ)?
A: The MOQ for standard sizes is 100 pieces. For custom dimensions or colors, the MOQ may be higher – please confirm with our sales representative.
