Help CenterFRP U Channel 80mm x 40mm x 4mm, Pultrusion Process, High Strength, Non-Conductive, for Solar Panel Mounting
Product Spotlights
Related Products
-
FRP U Channel for Cable Tray Systems, Corrosion Resistant, Lightweight, 50mm x 25mm x 3mm, Easy InstallationNegotiableMOQ: 300 Square Meters -
FRP U Channel Profile 40mm x 20mm x 2mm, 2.0g/cm³ Density, 300MPa Flexural Strength for Structural SupportNegotiableMOQ: 300 Square Meters
-
FRP U Channel Used in Bridge Construction, High Load Capacity, 120mm x 60mm x 8mm, Anti-Slip SurfaceNegotiableMOQ: 300 Square Meters
-
FRP U Channel Reliable Supply, 24/7 Customer Service, Custom Lengths Available, No Minimum Order QuantityNegotiableMOQ: 300 Square Meters
-
FRP U Channel With 2-Year Warranty, Free Technical Support, Mill Test Report Provided for Each BatchNegotiableMOQ: 300 Square Meters
Hengshui Ruibin New Materials LLC is a professional manufacturer of FRP profiles with over 5 years of experience. Our FRP U Channel 80mm x 40mm x 4mm, produced through the advanced pultrusion process, offers exceptional strength, non-conductive properties, and excellent durability. Designed specifically for solar panel mounting systems, this lightweight yet robust channel provides reliable support in residential, commercial, and utility-scale installations. With a factory covering 1,000-3,000 square meters and a team of 101-200 skilled employees, we ensure consistent quality and timely delivery.
The pultrusion process creates a continuous fiber-reinforced polymer composite that is uniformly strong and void-free. This U channel exhibits a high strength-to-weight ratio, making it easy to handle while reducing structural load. Its non-conductive nature eliminates the risk of electrical shorts, ideal for photovoltaic applications. The material is also highly resistant to corrosion, UV radiation, and harsh weather conditions, ensuring long service life even in coastal or industrial environments.
Key Features & Technical Specifications
- Dimensions: 80mm (width) x 40mm (height) x 4mm (wall thickness)
- Material: E-glass fiber + vinyl ester or polyester resin
- Process: Continuous pultrusion for consistent quality
- Color: Available in standard or custom colors (RAL codes)
- Length: Customizable up to 12 meters; standard 6m
- Thermal Stability: Operates from -40°C to +80°C
- Fire Resistance: Self-extinguishing (optional fire retardant grade)
- Non-Conductive: Dielectric strength > 12 kV/mm
| Parameter | Value |
|---|---|
| Tensile Strength | ≥ 300 MPa |
| Flexural Strength | ≥ 400 MPa |
| Density | 1.8 - 2.0 g/cm³ |
| Water Absorption | ≤ 0.2% (24h) |
| Operating Temperature | -40°C to +80°C |
Advantages for Solar Panel Mounting
- Electrical Safety: Non-conductive material eliminates grounding risks and reduces installation complexity.
- Corrosion Resistance: No rust or degradation in salty, humid, or chemical-laden environments.
- Lightweight: Approximately 30% lighter than equivalent steel profiles, reducing transport and handling costs.
- Easy Fabrication: Can be cut, drilled, and assembled with standard tools; compatible with common fasteners.
- Thermal Insulation: Low thermal conductivity prevents heat transfer, improving system efficiency.
- Long Service Life: UV-stabilized resin ensures minimal color fading and structural integrity for 20+ years.
Our FRP U channel meets the rigorous demands of solar mounting systems, providing a stable platform for photovoltaic panels. The 80x40mm cross-section offers excellent load-bearing capacity while the 4mm wall thickness guarantees rigidity. Installation is straightforward with standard brackets and clamps, reducing labor time.
Company Strength & Trust
Hengshui Ruibin New Materials LLC has been a trusted manufacturer since 2019, with an annual export value of US$2.5 Million - US$5 Million. Our products are shipped worldwide via the ports of Tianjin and Qingdao, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We hold ISO9001 and ISO9000 certifications, ensuring every product meets strict quality control standards. With a dedicated R&D team and flexible production capacity, we can customize lengths, colors, and even resin formulations to meet specific project requirements.
We invite you to experience the superior performance of our FRP U channel for your next solar installation. Whether you need a small sample or a large container order, we are ready to provide competitive pricing, fast delivery, and professional technical support. Contact us today for a quote or to discuss your custom requirements.
Frequently Asked Questions
-
Q: What is the standard length of the FRP U channel?
A: Standard length is 6 meters, but we can customize lengths from 1m to 12m per your request. -
Q: Is this product suitable for ground-mounted solar systems?
A: Yes, the 80x40x4mm U channel provides excellent structural support for both roof and ground-mounted solar arrays. -
Q: Can this material be painted or coated?
A: Yes, the surface can be painted with appropriate primers. We also offer custom color options during production. -
Q: How does the FRP channel compare to aluminum or steel?
A: FRP is non-conductive, corrosion-proof, and about 30% lighter than steel. It does not rust like steel and has lower thermal conductivity than aluminum. -
Q: What is the maximum load capacity of this channel?
A: Load capacity depends on span and support conditions. Typically, a 1m span can support over 500 kg uniformly distributed load. Please provide your specific requirements for engineering data. -
Q: Do you offer samples?
A: Yes, we can provide small samples (e.g., 30cm length) for evaluation. Shipping cost is negotiable. -
Q: Is the product UV resistant?
A: Yes, the resin formulation includes UV stabilizers to prevent degradation from sunlight exposure. -
Q: What packaging do you use for export?
A: We pack the channels in bundles with plastic wrapping, strapping, and wooden pallets or crates to ensure safe transit.
Hengshui Ruibin New Materials LLC – Your reliable partner in advanced composite solutions. Contact us for more details or to place an order.
